Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall desk dimensions | 2000 x 1000 x 760 mm | |
|---|---|---|
| Work surface height | 760 mm | |
| Desktop thickness | 32 mm | |
| Raised side panel thickness | 19 mm | |
| Plinth base height | 80 mm | |
| Cable grommet diameter | 60 mm | |
| Under-desk knee clearance height | 600 mm | |
| Under-desk knee clearance depth | 650 mm | |
| Edge band thickness | 2 mm | |
| Drawer internal depth (file storage) | 400 mm | |
| Modesty panel full height | 680 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Desktop static even load capacity | 120 kg | |
|---|---|---|
| File drawer maximum load | 16 kg | |
| Box drawer maximum load | 7 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Hinge cycle rating for cabinet doors | 80000 cycles | |
| Desk net weight | 144 kg | |
| Cable tray maximum load | 5 kg | |
| Leveling glide adjustment range | 15 mm | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desktop surface | Plain sliced cherry veneer over 45lb density particleboard core | |
|---|---|---|
| Frame and moldings | Solid hardwood trim and raised panel frames | |
| Base plinth | MDF wrapped with matching wood veneer, finished with catalyzed satin varnish | |
| Drawer components | Plywood drawer sides/backs, dovetail joinery, 3-ply drawer bottoms | |
| Hardware components | Zinc alloy lock cores, steel ball-bearing drawer slides, ABS cable grommets | |
| Surface finish | Catalyzed varnish topcoat, scratch and stain resistant |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable management system | Three 60mm desktop grommets aligned along rear edge, with under-desk cable tray | |
|---|---|---|
| Drawer storage system | Lockable central pencil drawer plus two locking file drawers for legal/letter folders | |
| Floor leveling system | Adjustable glides installed at all four base corners | |
| Modesty panel function | Full-height raised panel along visitor-facing side, blocking under-desk view |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Private executive office | Formal traditional styling matches senior management private office interiors | |
|---|---|---|
| Government and institutional offices | Conservative dark wood finish suitable for formal public sector workspaces |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables and desks, dimensional and safety requirements for commercial office use | |
|---|---|---|
| EN 13722:2004 | Furniture strength and durability requirements for storage units integrated into desks |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard, applicable for load, stability and durability testing |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural performanceAcceptance | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials limit of harmful substances, applicable for formaldehyde emission testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural performanceAcceptance; 2. GB 18584-2001: Indoor decorating and refurbishing materials limit of harmful substances, applicable for formaldehyde emission testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
