Automatic mm / inch conversion · Core engineering specifications
| Overall footprint | 1600 x 1600 x 1200 mm | |
|---|---|---|
| Worktop height | 750 mm | |
| Worktop thickness | 22 mm | |
| Worktop segment depth | 600 mm | |
| Partition panel total height | 1200 mm | |
| Lower fabric partition height | 900 mm | |
| Upper open frame height | 300 mm | |
| Knee well clearance width | 800 mm | |
| Knee well clearance height | 600 mm | |
| Mobile pedestal dimensions | 400 x 440 x 580 mm | |
| Fixed end cabinet depth | 600 mm | |
| Cable grommet diameter | 60 mm | |
| Partition frame profile width | 40 mm | |
| Leveling foot height adjustment | 15 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Static worktop uniform load capacity | 90 kg | |
|---|---|---|
| Mobile pedestal drawer static load | 30 kg | |
| Total workstation net weight | 120 kg | |
| Partition frame wall thickness | 1.2 mm | |
| Fabric panel acoustic noise reduction coefficient | 0.35 | |
| Recommended user weight capacity | 136 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Product warranty period | 5 years | |
| Available color configurations | 6 | |
| Reference Static Load | 150 kg depending on category |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop surface | 22mm melamine-faced particleboard with matching PVC edge banding | |
|---|---|---|
| Privacy partition panels | 25mm medium-density fiberboard core wrapped with grey woven polyester fabric | |
| Partition support frame | Powder-coated grey steel and aluminum alloy modular connector system | |
| Fixed end cabinet panels | 18mm white melamine-faced particleboard with edge banding | |
| Mobile pedestal construction | 0.8mm thick cold-rolled steel with white powder coat finish | |
| Modesty panel | 18mm grey melamine-faced particleboard | |
| Hardware components | Zinc-plated steel cam locks, connector brackets, handles and leveling feet | |
| Cable management components | ABS plastic round cable grommet, aluminum under-panel cable raceway | |
| Mobile pedestal casters | 50mm diameter black nylon swivel casters, 2 with locking brake | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Cable management system | Round desktop grommet routes cords to under-panel raceways for separate power/data wiring | |
|---|---|---|
| Floor leveling adjustment | 15mm adjustable glides on frame and cabinet bases compensate for uneven floor surfaces | |
| Mobile pedestal storage | 3-drawer unit (pencil tray, utility drawer, hanging file drawer) with central lock, rolls fully under work surface | |
| Fixed end storage | Two integrated full-height cabinet units at worktop ends for stationary and supply storage | |
| Privacy partition function | Partial-height fabric panels block seated sightlines and reduce conversational noise between adjacent workstations | |
| Modular reconfiguration | Metal frame connectors allow panel and worktop rearrangement to alternate cubicle layouts | |
| Work surface layout | Curved inner L-corner creates seamless elbow-friendly transition between two work segments | |
| Drawer operation | Full-extension ball-bearing drawer slides allow 100% access to stored files and supplies | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Open-plan office spaces | Provides individual private work zones in high-density open office layouts for focus work | |
|---|---|---|
| Small business admin areas | All-in-one workstation with built-in storage reduces need for separate freestanding furniture | |
| Call center seating rows | Partial-height partitions reduce cross-talk distraction while allowing supervisor visibility | |
| Temporary project team zones | Modular construction allows fast reconfiguration to match changing team size needs | |
| Home office dedicated work spaces | All-in-one design with storage suits remote workers needing structured, private work areas | |
| Startup office fit-outs | Standard commercial specification supports fast, cost-effective bulk office furnishing |
EU Market Access Requirements* EN Standards
| EN 527-2:2002+A1:2019 | Office worktables safety and strength requirements, applicable to worktop load and stability testing | |
|---|---|---|
| EN 1335-1:2020 | Office furniture seating dimensions reference, applicable to knee well clearance for seated use | |
| EN 1023-2:2019 | Office storage furniture safety requirements, applicable to fixed and mobile cabinet construction |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard, applicable to worktop load, durability and stability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard, applicable to mobile and fixed cabinet load and cycle testing | |
| ANSI/BIFMA X7.1-2020 | Formaldehyde emission standard for low-emitting office furniture, applicable to panel components |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable to worktop and cabinet panel construction | |
|---|---|---|
| GB/T 35607-2017 | Limit of harmful substances in office furniture, applicable to formaldehyde emission testing for panel components | |
| GB/T 24821-2009 | Office desk performance test methods, applicable to static load and stability verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable to worktop and cabinet panel construction; 2. GB/T 35607-2017: Limit of harmful substances in office furniture, applicable to formaldehyde emission testing for panel components; 3. GB/T 24821-2009: Office desk performance test methods, applicable to static load and stability verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
