Automatic mm / inch conversion · Core engineering specifications
| Overall footprint | 1400 x 1400 x 1200 mm | |
|---|---|---|
| Work surface height | 750 mm | |
| Desktop thickness | 25 mm | |
| Partition screen height | 1200 mm | |
| Partition panel thickness | 40 mm | |
| Desktop edge band thickness | 2 mm | |
| Cable grommet diameter | 60 mm | |
| Knee clearance height under desk | 650 mm | |
| Knee clearance width at corner | 800 mm | |
| Mobile pedestal dimensions | 450 x 550 x 560 mm | |
| Pedestal caster diameter | 50 mm | |
| Desk support leg wall thickness | 1.5 mm | |
| Modesty panel height | 400 mm | |
| Desktop depth along main work side | 600 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat |
Net weight / load capacity / users / durability
| Desktop uniform static load capacity | 150 kg | |
|---|---|---|
| Drawer slide open/close cycle rating | 50000 cycles | |
| Recommended maximum user weight for workspace | 120 kg | |
| Product net weight reference | 110 kg | |
| Fabric partition sound dampening rating | 25 dB | |
| Melamine finish surface hardness | 3H | |
| Melamine finish abrasion resistance | 20000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop core | E0 grade high-density fiberboard, density 750kg/m³ | |
|---|---|---|
| Desktop finish | Textured light oak melamine laminate | |
| Desktop edging | 2mm thick PVC edge banding | |
| Partition fabric | B1 flame-retardant sage green polyester fabric | |
| Partition frame | 1.2mm thick dark gray powder-coated cold-rolled steel | |
| Desk support structure | 1.5mm thick powder-coated cold-rolled steel legs | |
| Mobile pedestal body | Matching melamine-faced engineered board | |
| Drawer hardware | 3-section silent steel ball-bearing slides | |
| Pedestal casters | 50mm diameter black nylon swivel casters | |
| Modesty panels | 16mm thick melamine-faced engineered board | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Cable management system | 60mm round corner grommet with hidden under-desk channel routes power and data cables from work surface to floor | |
|---|---|---|
| Mobile pedestal storage | 3 lockable drawers on casters: 2 stationery drawers, 1 hanging file drawer for A4/letter documents | |
| Partition privacy system | 1200mm high two-sided fabric dividers block direct sight lines between adjacent workstations | |
| Adjustable foot pads | 10mm height-adjustable anti-slip pads on desk legs compensate for 10 mm uneven floor surfaces | |
| Drawer locking mechanism | Central key lock secures all 3 pedestal drawers simultaneously | |
| Curved corner work surface | Smooth rounded inner corner edge allows seamless transition between two work zones, no sharp corners at seating position | |
| Modesty panel coverage | 400mm high front panels under both desk segments block view of seated user's legs from outside the cubicle | |
| Pedestal caster locking | 2 lockable swivel casters fix pedestal position under desk when in use, unlock for repositioning | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Total shipping gross weight | 110 kg | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open plan office spaces | Single-seat cubicle provides individual work privacy in open office layouts, reduces visual and noise distraction | |
|---|---|---|
| Small business office setups | Compact L-footprint fits in small office footprints without requiring large floor space | |
| Government and institutional offices | Durable construction meets high-traffic institutional use requirements, lockable storage secures official documents | |
| Call center and shared work hubs | Partitioned layout creates semi-private zones for focused work or call handling, mobile pedestal stores personal items | |
| Home office dedicated work zones | Curved corner design fits residential corner spaces, provides ample work surface and storage for remote work | |
| Temporary project office setups | Knock-down design allows easy disassembly and relocation for short-term project sites |
EU Market Access Requirements* EN Standards
| EN 527-2:2002+A1:2019 | Applicable for safety, strength and durability requirements for office work desks | |
|---|---|---|
| EN 1335-2:2018 | Applicable reference for ergonomic clearance dimensions for seated office workstations | |
| EN 1022:2018 | Applicable for stability testing requirements for freestanding office furniture |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Applicable reference for desk structural load and durability testing for commercial office use | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Applicable reference for mobile storage pedestal performance and durability requirements |
Standards applicable to China-market projects
| GB 18580-2017 | Applicable for formaldehyde emission limits of engineered wood panels used in desk and pedestal, recommended limit ≤0.124mg/m³ | |
|---|---|---|
| GB/T 3324-2017 | Applicable for general technical requirements of wooden office furniture, including dimensional stability and structural strength | |
| GB 20286-2006 | Applicable for flame retardant performance of fabric partition panels in public office spaces | |
| GB/T 3327-2016 | Applicable for performance and durability requirements of office desks and workstations |
This product must meet the following technical requirements: 1. GB 18580-2017: Applicable for formaldehyde emission limits of engineered wood panels used in desk and pedestal, recommended limit ≤0.124mg/m³; 2. GB/T 3324-2017: Applicable for general technical requirements of wooden office furniture, including dimensional stability and structural strength; 3. GB 20286-2006: Applicable for flame retardant performance of fabric partition panels in public office spaces; 4. GB/T 3327-2016: Applicable for performance and durability requirements of office desks and workstations; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
