Automatic mm / inch conversion · Core engineering specifications
| Overall unit dimensions | 2820 x 1420 x 1219 mm | |
|---|---|---|
| Work surface height | 760 mm | |
| Per-workstation surface size | 1200 x 600 mm | |
| Privacy divider height | 1219 mm | |
| Worktop thickness | 32 mm | |
| Under-desk pedestal dimensions | 406 x 432 x 660 mm | |
| Knee clearance height under worktop | 660 mm | |
| Tapered metal leg height | 100 mm | |
| PVC edge banding thickness (worktop) | 1 mm | |
| PVC edge banding thickness (divider/panel) | 0.5 mm | |
| Open shelf clearance above drawer | 120 mm | |
| Drawer internal usable height | 100 mm | |
| Lower cabinet internal usable height | 400 mm | |
| Cable grommet diameter | 60 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Total product net weight | 73 kg | |
|---|---|---|
| Per-worktop static load capacity | 91 kg | |
| Seating capacity per unit | 2 users | |
| Fabric divider sound dampening rating | 15 dB | |
| Melamine surface scratch resistance | 2000 cycles | |
| Commercial structural warranty | 5 years | |
| Available color finish options | 2 | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface | E1 grade melamine-laminated particleboard, light washed oak finish | |
|---|---|---|
| Privacy dividers | Sage green woven fabric over MDF core, dark powder-coated metal frame | |
| Upper divider decorative section | Patterned perforated rigid panel with matching dark frame | |
| Drawer front panel | Sage green matte laminated MDF with round dark metal pull handle | |
| Lower cabinet door | Light oak finish fluted vertical-groove laminated MDF | |
| Storage cabinet body and shelves | 16mm thick melamine-laminated particleboard, light oak finish | |
| Cabinet back panel | 6mm thick hardboard/MDF with light matching finish | |
| Support legs | 1.2mm thick tapered mild steel, dark powder-coated finish | |
| Drawer slides | Cold-rolled steel 3/4 extension smooth-glide slides | |
| Cable grommets | ABS plastic, dark finish to match metal framing | |
| Edge banding | PVC material, color-matched to light oak finish | |
| Leg foot pads | Non-slip nylon adjustable levelers |
Adjustment / rotation / tilt / mobility / storage features
| Privacy screening | Fabric dividers block direct line of sight between adjacent seated users | |
|---|---|---|
| Cable management | Dual desktop grommets route power/data cables from surface to floor | |
| Drawer storage | Single drawer per station stores pens, notepads, and small personal items | |
| Lower enclosed storage | Fluted-door lower cabinet secures bulkier items and personal belongings | |
| Floor leveling | Adjustable nylon foot pads on each leg compensate for uneven floor surfaces | |
| Modular connection | Integrated frame allows alignment with additional matching workstation units | |
| Surface protection | Stain and scratch resistant melamine finish resists coffee spills and daily office wear | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Open-plan office areas | Provides individual visual privacy for staff while supporting team collaboration | |
|---|---|---|
| Small business workspaces | Compact L-shaped dual layout maximizes floor space efficiency for growing teams | |
| Coworking spaces | Dedicated individual work zones with personal storage for hot-desking users | |
| Startup offices | Modern light wood and sage color scheme fits contemporary creative workspace design | |
| Call center environments | Low dividers reduce cross-talk distraction while allowing supervisor oversight |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable to worktop load testing | |
|---|---|---|
| EN 527-2:2016 | Office worktables dimensional requirements for seated work positions | |
| EN 1335-2:2018 | Reference for under-desk clearance dimensions to accommodate office task chairs |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products safety and performance standard for commercial office use | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard applicable to integrated pedestals |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to laminated panel workstations | |
|---|---|---|
| GB/T 3327-2016 | Test methods for stability of furniture, applicable to desk anti-tip verification | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, minimum E1 grade required for panel components |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to laminated panel workstations; 2. GB/T 3327-2016: Test methods for stability of furniture, applicable to desk anti-tip verification; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, minimum E1 grade required for panel components; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
