Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall assembly footprint | 3600 x 2400 x 1100 mm | |
|---|---|---|
| Desktop working height | 750 mm | |
| Single L-shaped workstation surface | 1400 x 1200 mm | |
| Desktop panel thickness | 25 mm | |
| Partition total thickness | 83 mm | |
| Partition height above desktop | 350 mm | |
| Seated knee clearance height | 650 mm | |
| Curved knee cutout radius | 300 mm | |
| Cable grommet diameter | 60 mm | |
| Under-desk mobile pedestal dimension | 400 x 500 x 600 mm | |
| PVC edge banding thickness | 2 mm | |
| Modesty panel height | 400 mm | |
| Aluminum partition frame wall thickness | 1.2 mm | |
| CPU holder clearance | 250 x 500 x 450 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Single desktop static load capacity | 100 kg | |
|---|---|---|
| Total workstation net weight | 280 kg | |
| Recommended user weight per station | 120 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Frame surface abrasion resistance | 2000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desktop panel | 25mm E1 grade melamine-faced particleboard, light maple finish | |
|---|---|---|
| Partition frame | 1.2mm thick electrostatic powder-coated aluminum alloy, silver finish | |
| Lower partition panel | Tackable green fabric over high-density fiberboard core | |
| Upper partition panel | Frosted translucent acrylic/polycarbonate panel with horizontal vent slots | |
| Edge banding | 2mm thick scratch-resistant PVC, color-matched to desktop | |
| Desk support frame | 1.2mm thick powder-coated square steel tubing, white finish |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable management | 60mm diameter desk grommets at each station corner with under-desk cable trays | |
|---|---|---|
| Modular connection | Aluminum profile slot-in connector system for frames and panels | |
| Storage integration | Compatible with under-desk mobile pedestals and fixed CPU holders | |
| Privacy screening | 350mm high upper divider blocks direct line of sight between adjacent seated users |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open plan office spaces | Provides divided individual workstations for 6 staff with shared central partition core | |
|---|---|---|
| Call center and customer service teams | Offers balanced privacy and visibility for team supervision and individual focus |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable to desk surfaces | |
|---|---|---|
| EN 1023-2:2000 | Office storage furniture strength and stability, applicable to pedestal units | |
| EN 13722:2004 | Office furniture partition systems performance requirements, applicable to cubicle dividers | |
| EN 13986:2004 | Wood-based panels for structural use, applicable to MFC desk components |
US and Canada office-furniture standards
| ANSI/BIFMA X5.1-2017 | Office desk safety and durability standard, applicable to desktop load and stability | |
|---|---|---|
| ANSI/BIFMA X5.3-2019 | Vertical files and mobile pedestals performance standard, applicable to drawer units | |
| ANSI/BIFMA X5.6-2016 | Office panel systems performance standard, applicable to partition structures | |
| ANSI/BIFMA X5.9-2019 | Office storage units performance standard, applicable to under-desk components |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk panel and cabinet components | |
|---|---|---|
| GB/T 3327-2017 | Office furniture performance test for desks, applicable to structural load and stability | |
| GB 18580-2017 | Formaldehyde emission limit for wood-based panels, applicable to particleboard components | |
| GB/T 24821-2009 | Office panel furniture partition systems, applicable to cubicle divider structure |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk panel and cabinet components; 2. GB/T 3327-2017: Office furniture performance test for desks, applicable to structural load and stability; 3. GB 18580-2017: Formaldehyde emission limit for wood-based panels, applicable to particleboard components; 4. GB/T 24821-2009: Office panel furniture partition systems, applicable to cubicle divider structure; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
