Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Finished Top Thickness | 50 mm | |
|---|---|---|
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Recommended working load on transaction top | 80 kg | |
|---|---|---|
| Recommended writing-surface load | 60 kg | |
| Open shelf load per level | 15 kg | |
| Drawer load capacity | 20 kg per drawer | |
| Seating capacity | 1 staff member | |
| Transaction capacity | 2 standing visitors | |
| Product net weight | 125 kg | |
| Suggested maximum desktop equipment weight | 25 kg | |
| Adjustable foot leveling range | 10 mm | |
| Top Static Load Reference | 150 kg uniformly distributed |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Transaction and writing worktops | 25 mm melamine-faced particleboard with warm oak grain and sealed exposed edges | |
|---|---|---|
| Off-white carcass panels | 18 mm melamine-faced particleboard with square edge banding | |
| Dark modesty panel | 18 mm charcoal-gray melamine panel with a horizontal lower rail | |
| Upper privacy screen | Frosted translucent acrylic or glass insert in a dark gray aluminum-look frame with horizontal louver pattern | |
| Drawer fronts | 18 mm warm oak-grain melamine-faced board with black horizontal reveal lines | |
| Open shelves | 18 mm light gray or off-white melamine-faced board fixed into cabinet dividers | |
| Cabinet back and inner dividers | 18 mm laminated panel-board partitions forming separate equipment and storage bays | |
| Drawer lock | Keyed cylinder lock with black rectangular escutcheon and silver insert | |
| Leveling feet | Black circular nylon or PVC feet with metal threaded stems | |
| Hardware and connectors | Cam-and-dowel panel connectors with concealed screw fixings | |
| Edge protection | PVC or ABS edge banding on high-use worktop and exposed case edges | |
| Surface finish | Matte wood-grain laminate on work zones and smooth matte solid-color laminate on cabinet panels |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Visitor transaction service | 1050 mm high front counter supports standing reception, document handover, and visitor check-in | |
|---|---|---|
| Staff writing position | 750 mm inner work surface with 700 mm knee bay supports seated computer or paperwork tasks | |
| Front privacy screening | 350 mm high framed louvered screen limits direct sightlines while retaining light transmission | |
| Open document storage | Two upper cubbies and one lower open shelf provide separate storage for brochures, forms, and equipment compartments | |
| Lockable drawer storage | Keyed lock secures the upper shallow drawer and adjacent drawer stack for confidential reception items | |
| Vertical filing storage | 520 mm lower drawer front provides suspended-file or bulk-storage depth for reception documents | |
| Cable management | White oval cable grommet on the main worktop routes power and data cables into the desk cavity | |
| Floor leveling | Threaded black feet compensate for uneven reception-area floors and keep panels square | |
| Modular reception configuration | L-shaped panels can be installed against a wall or as a corner reception unit with one staff entry side | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Corporate office reception | Suitable for entry lobbies where one receptionist handles visitors, couriers, and access control | |
|---|---|---|
| Medical or service front desk | Usable for clinics, agencies, and service centers requiring privacy screening and locked document storage | |
| Small hotel or club lobby | Fits compact welcome areas for registration, key cards, concierge supplies, and guest inquiries | |
| Open-plan admin workstation | Can serve as a corner administrative desk with storage hutch for forms, printer paper, and telecom equipment | |
| School or training center reception | Supports enrollment, visitor sign-in, and document storage in a single staffed position | |
| Recommended reception chair | Use a task chair with 440 to 520 mm adjustable seat height to fit the 750 mm inner work surface | |
| Recommended counter equipment pairings | Pair with a compact monitor, visitor sign-in tablet, telephone, label printer, and under-counter CPU shelf |
EU Market Access Requirements* EN Standards
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.5 Desk and Table Products |
|---|
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
