2-Person L-Shaped Office Cubicle Workstation Set with Low Dividers and Mobile Pedestal (model WS-L2-1400-BW) is listed under L-Shaped Office Desk, with overall dimensions of 2800 × 1200 × 1050 mm and main material of Particle‑board (PB). Load capacity: 100 kg. Certifications: Modular,workstation,2-seat,L-shaped,layout,low,divider,screens,under-desk,storage,pedestal. This page consolidates 6 groups of specifications and GB / EN / ANSI/BIFMA standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall set dimensions | 2800 x 1200 x 1050 mm | |
|---|---|---|
| Per-user main work surface | 1400 x 600 mm | |
| Per-user return work surface | 1200 x 600 mm | |
| Standard work surface height | 750 mm | |
| Work surface thickness | 25 mm | |
| Under-desk knee clearance height | 660 mm | |
| Low privacy divider height | 300 mm | |
| Divider panel thickness | 32 mm | |
| Side modesty panel height | 420 mm | |
| Metal frame tube profile | 30 x 30 mm | |
| Desktop cable grommet diameter | 60 mm | |
| Mobile pedestal dimensions | 400 x 500 x 600 mm | |
| Caster diameter for pedestal | 100 mm | |
| PVC edge banding thickness | 2 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Single work surface static load capacity | 100 kg | |
|---|---|---|
| Set total net weight | 180 kg | |
| Noise reduction rating of dividers | 35 dBA | |
| Leveling foot adjustment range | 15 mm | |
| Drawer slide cycle rating | 50000 open/close cycles | |
| Work surface finish abrasion resistance | 2000 cycles | |
| Structural warranty period | 5 years | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Work surface core | E1 grade particleboard with thermally fused melamine laminate | |
|---|---|---|
| Edge protection | 2mm thick PVC edge banding, impact-sealed around worktop perimeter | |
| Support frame | 1.2mm thick powder-coated square steel tube, matte black/white finish | |
| Privacy panels | Fabric-wrapped hardboard core over steel partition frame | |
| Mobile pedestal | 0.8mm thick steel cabinet body with white powder-coat finish | |
| Hardware components | Zinc-plated steel brackets, full-extension ball bearing slides, lockable top drawer |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable management system | 60mm desktop grommets paired with under-desk wire trays, routes power/data cords neatly | |
|---|---|---|
| Floor leveling system | Adjustable threaded feet on each frame leg, compensates for 15mm floor unevenness | |
| Mobile pedestal mobility | 4 dual-wheel swivel casters on pedestal, allows repositioning under desk, lockable top drawer for secure storage | |
| Modular configuration | Bolt-together frame design supports reconfiguration to single or extended workstation layouts |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open plan office spaces | Provides dedicated separated work zones for 2 staff in open office layouts | |
|---|---|---|
| Small business staff work areas | Space-efficient L-corner design maximizes work surface per square meter |
EU Market Access Requirements* EN Standards
| EN 527-2:2002+A1:2019 | Office work tables safety and strength requirements, applies to work surface performance | |
|---|---|---|
| EN 1335-2:2018 | Office furniture stability and strength for seating adjacent to workstations | |
| EN 71-3:2019 | Migration of certain elements, for non-toxic finish compliance |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard, applicable to load and stability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard, applicable to mobile pedestal durability |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to worktop and cabinet components | |
|---|---|---|
| GB/T 3325-2017 | Metal furniture general technical requirements, applicable to steel frame and pedestal | |
| GB 18580-2017 | Formaldehyde emission limit for wood-based panels, E1 grade requirement for worktops |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to worktop and cabinet components; 2. GB/T 3325-2017: Metal furniture general technical requirements, applicable to steel frame and pedestal; 3. GB 18580-2017: Formaldehyde emission limit for wood-based panels, E1 grade requirement for worktops; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
