3-Person 120-Degree Curved Corner Office Cubicle Workstation with Fabric and Frosted Glass Partitions (model CUB-120-3P-WS) is listed under L-Shaped Office Desk, with overall dimensions of 2866 × 2480 × 1200 mm and main material of Particle‑board (PB). Load capacity: 100 kg. Certifications: Modular,partitioned,structure,120-degree,corner,cluster,fabric-frosted,glass,divider,under-desk,storage,open-plan,design. This page consolidates 6 groups of specifications and GB / EN / ANSI/BIFMA standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall workstation footprint | 2866 x 2480 x 1200 mm | |
|---|---|---|
| Work surface height | 750 mm | |
| Per-user curved work surface size | 1400 x 750 mm | |
| Partition panel total height | 1200 mm | |
| Frosted glass partition section thickness | 30 mm | |
| Fabric partition panel thickness | 60 mm | |
| Under-desk knee clearance height | 680 mm | |
| Under-desk knee clearance depth | 450 mm | |
| Mobile storage pedestal dimensions | 400 x 580 x 645 mm | |
| Steel support leg profile | 60 x 30 mm | |
| Cable grommet diameter | 80 mm | |
| Adjustable foot height adjustment range | 10 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total product static weight | 200 kg | |
|---|---|---|
| Work surface uniform static load capacity | 100 kg | |
| Recommended user weight for paired task chair | 120 kg | |
| Melamine surface scratch resistance | 2000 cycles | |
| Warranty period | 5 years | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Work surface | 25mm thick E1 grade melamine-faced particleboard with 2mm PVC edge banding | |
|---|---|---|
| Support frame | Powder-coated square steel legs with cross-braced underframe | |
| Partition frame | Anodized aluminum extrusion profile for divider panels | |
| Partition infill panels | Fabric-upholstered tackable panel with upper frosted tempered glass section | |
| Storage pedestals | 18mm thick melamine-faced particleboard with lockable drawer fronts | |
| Leveling components | Nylon adjustable feet with steel threaded inserts |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable management | Integrated under-desk cable trunking with 80mm desktop grommets for wire routing | |
|---|---|---|
| Partition modularity | Aluminum-framed panels connect at 120-degree angles for clustered layout | |
| Storage mobility | Mobile pedestals fitted with lockable casters for flexible under-desk positioning | |
| Floor leveling | Adjustable feet compensate for 10mm of floor unevenness to stabilize work surfaces |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open-plan office spaces | Modular clustered design for call centers, admin teams and back-office departments | |
|---|---|---|
| Corporate staff work areas | 1200mm high partitions balance privacy and collaborative visibility for team workspaces |
EU Market Access Requirements* EN Standards
| Office furniture safety requirements | EN 527:2011 | |
|---|---|---|
| Office furniture stability testing | EN 527:2002 | |
| Formaldehyde emission for wood panels | EN 13986:2004 |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.5 Desk and Table Products |
|---|
Standards applicable to China-market projects
| Desktop panel formaldehyde emission | GB/T 17657 | |
|---|---|---|
| Furniture structural stability | GB/T 10357.1 | |
| Metal surface coating adhesion | GB/T 9286 |
This product must meet the following technical requirements: 1. Desktop panel formaldehyde emission: GB/T 17657; 2. Furniture structural stability: GB/T 10357.1; 3. Metal surface coating adhesion: GB/T 9286; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
