Automatic mm / inch conversion · Core engineering specifications
| Overall cluster footprint | 2400 x 2400 x 1350 mm | |
|---|---|---|
| Work surface height above floor | 750 mm | |
| Individual work surface size per user | 1200 x 600 mm | |
| Under-desk knee clearance height | 620 mm | |
| Under-desk knee clearance depth | 550 mm | |
| Partition panel total thickness | 60 mm | |
| Lower fabric privacy panel height | 900 mm | |
| Upper frosted glass panel height | 300 mm | |
| Mobile pedestal overall size | 400 x 500 x 600 mm | |
| Cable grommet diameter | 80 mm | |
| Partition frame profile width | 30 mm | |
| Caster wheel diameter on pedestal | 50 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Static uniform load per work surface | 300 kg | |
|---|---|---|
| Mobile pedestal drawer static load capacity | 25 kg | |
| Net weight per complete workstation set | 165 kg | |
| Recommended number of users | 2 | |
| Work surface abrasion resistance cycles | 2000 | |
| Leveler foot vertical adjustment range | 15 mm | |
| Pedestal caster dynamic load rating per wheel | 40 kg | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface substrate and finish | 25mm thick E1 grade MFC with 2mm PVC edge banding, anti-scratch melamine finish | |
|---|---|---|
| Partition support frame | Powder-coated aluminum alloy extruded profiles, bronze-toned finish | |
| Lower privacy panel base | 12mm thick MDF core covered with ribbed woven polyester fabric | |
| Upper partition panels | 5mm thick frosted semi-transparent tempered safety glass | |
| Mobile pedestal cabinet body | 0.8mm thick cold-rolled steel with epoxy powder coat finish, white and two-tone gray | |
| Pedestal drawer and door hardware | Zinc alloy lock cores, aluminum pull handles, plastic drawer glides | |
| Pedestal mobility components | Black hard nylon swivel casters, 360-degree rotation, two braked units per pedestal | |
| Base leveling components | Nylon-padded steel adjustable leveler feet at all partition base corners | |
| Cable management components | ABS plastic round cable grommet, integrated under-desk plastic cable raceway | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Layout configuration | 90-degree cross-corner cluster forming two enclosed opposite-facing individual work zones | |
|---|---|---|
| Privacy partition function | Dual-height panels block seated sight lines while allowing natural light through upper glass sections | |
| Cable management system | Desktop grommet routes power and data cables to under-desk raceway for clutter-free wiring | |
| Mobile pedestal storage | One lockable unit per station with 1 shallow top drawer and 1 lower file cabinet, fully retracts under desk | |
| Floor level adjustment | Threaded leveler feet at frame bases compensate for uneven floors to keep work surfaces level | |
| Pedestal mobility | Swivel casters allow storage units to be moved for cleaning or reconfiguration, brakes lock unit in place | |
| Modular reconfiguration | Aluminum frame connections allow addition of extra stations or partition panels for future layout changes | |
| Storage security | Keyed lock on each pedestal secures personal items and work documents from unauthorized access | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Open plan office staff zones | Suitable for two-person team clusters in open office layouts, providing individual privacy | |
|---|---|---|
| Small business administrative areas | Fits compact office spaces for administrative, data entry or customer support staff | |
| Call center workstations | Acoustic privacy from fabric panels supports focused phone and computer work for call center agents | |
| Startup team work areas | Modular design allows easy reconfiguration as team sizes change over time | |
| Government and corporate back offices | Durable construction meets heavy daily use requirements for permanent back-office staff positions | |
| Recommended pairing | Pairs with standard mid-back ergonomic task chairs, monitor arms and under-desk CPU holders for full workstation setup |
EU Market Access Requirements* EN Standards
| Office work surface dimensions | EN 527:2011 | |
|---|---|---|
| Office furniture mechanical stability | EN 14073:2004 | |
| Office chair/desk clearance compatibility | EN 1335:2020 |
US and Canada office-furniture standards
| Office desk load and durability | ANSI/BIFMA X2021 | |
|---|---|---|
| Mobile storage pedestal performance | ANSI/BIFMA X2019 |
Standards applicable to China-market projects
| Office desk work surface height | GB/T 3326 | |
|---|---|---|
| Office furniture mechanical safety | GB 28007 | |
| Wood-based panel formaldehyde emission | GB 18580 | |
| Office furniture storage unit stability | GB/T 10357.4 |
This product must meet the following technical requirements: 1. Office desk work surface height: GB/T 3326; 2. Office furniture mechanical safety: GB 28007; 3. Wood-based panel formaldehyde emission: GB 18580; 4. Office furniture storage unit stability: GB/T 10357.4; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
