Automatic mm / inch conversion · Core engineering specifications
| Overall footprint | 2800 x 2800 x 1100 mm | |
|---|---|---|
| Work surface height | 750 mm | |
| Privacy partition height | 1100 mm | |
| Single station L-arm length | 1400 mm | |
| Work surface depth | 600 mm | |
| Curved inner corner radius | 300 mm | |
| Under-desk knee clearance height | 690 mm | |
| Mobile pedestal dimensions | 400 x 500 x 600 mm | |
| Fixed side cabinet depth | 450 mm | |
| Worktop thickness | 25 mm | |
| Cable grommet diameter | 60 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Single worktop static load capacity | 150 kg | |
|---|---|---|
| Recommended user count | 2 | |
| Unit net weight reference | 185 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Partition panel flame retardancy | B1 grade | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop substrate | E0-grade high-density fiberboard, ≥720kg/m³ density | |
|---|---|---|
| Worktop finish | Wear-resistant, stain-proof melamine laminate | |
| Edge banding | 2mm thick PVC hot-melt edge sealing | |
| Support frame | 1.2mm thick cold-rolled steel, electrostatic powder coat | |
| Privacy partition surface | Polyester fabric wrapped panel with acoustic fill | |
| Partition top trim | Perforated steel vent panel for cable routing | |
| Mobile pedestal body | 0.8mm thick steel drawer box with lock | |
| Drawer slides | 3-section soft-close steel ball-bearing slides | |
| Casters | 50mm diameter hard nylon swivel casters, 2 with brake | |
| Fixed side cabinet panels | 18mm thick melamine-faced particleboard | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Privacy partition layout | Cross-shaped mid-height divider separating two opposite seated positions | |
|---|---|---|
| Mobile pedestal storage | Lockable 3-drawer rolling unit per user, fits fully under work surface | |
| Fixed side storage | Full-height closed cabinet adjacent to each work position for supplies | |
| Cable management system | Concealed raceway inside partitions plus desktop cable grommets | |
| Drawer operation | Full-extension soft-close slides with keyed lock for top drawer | |
| Modular assembly | Knock-down panel connection system for reconfiguration or expansion | |
| Knee access design | Curved corner cutout providing unobstructed leg room for each user | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Open plan office deployment | Suitable for corporate open-plan staff zones, providing individual seated privacy | |
|---|---|---|
| Small team workspace | Ideal for 2-person team clusters in administrative or departmental offices | |
| Call center and admin use | Appropriate for customer service, data entry, and general administrative roles | |
| Standard office configuration | Pairs with mid-back ergonomic office chairs and standard monitor arms | |
| Quick-deploy office fit-out | Suitable for fast-track office renovation projects with modular layout requirements |
EU Market Access Requirements* EN Standards
| Office furniture structural safety | EN 527:2002 | |
|---|---|---|
| Storage furniture stability | EN 14073:2004 | |
| Fabric flame resistance | EN 1021:2014 |
US and Canada office-furniture standards
| Desk load and durability | ANSI/BIFMA X2021 | |
|---|---|---|
| Mobile pedestal performance | ANSI/BIFMA X2019 |
Standards applicable to China-market projects
| Formaldehyde emission limit | GB 18584E0 grade ≤0.05mg/m³ | |
|---|---|---|
| Desk dimensional tolerance | GB/T 3326 | |
| Surface durability requirement | GB/T 4893.9 |
This product must meet the following technical requirements: 1. Formaldehyde emission limit: GB 18584E0 grade ≤0.05mg/m³; 2. Desk dimensional tolerance: GB/T 3326; 3. Surface durability requirement: GB/T 4893.9; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
