Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall footprint | 1600 x 1400 x 1070 mm | |
|---|---|---|
| Staff work surface height | 765 mm | |
| Raised transaction shelf height | 1070 mm | |
| Knee well opening width | 800 mm | |
| Knee well minimum clearance height | 650 mm | |
| Worktop panel thickness | 25 mm | |
| Privacy divider panel height | 320 mm | |
| Transaction shelf compartment depth | 300 mm | |
| Mobile pedestal dimensions | 400 x 550 x 600 mm | |
| Pull-out keyboard tray depth | 350 mm | |
| Curved work edge radius | 200 mm | |
| Cable grommet diameter | 60 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Worktop static load capacity | 80 kg | |
|---|---|---|
| Drawer slide cycle rating | 50000 cycles | |
| Unit net weight | 90 kg | |
| Recommended seated user capacity | 1 person | |
| Surface abrasion resistance | 2000 cycles | |
| Laminate stain resistance rating | Grade 4 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Worktop and shelf surfaces | 25mm thick MFC with light oak melamine laminate, 2mm PVC edge banding | |
|---|---|---|
| Cabinet and divider frames | 18mm thick MFC with white matte melamine finish, PVC edge banding | |
| Privacy divider upper section | White horizontal slatted MDF panel with white frame | |
| Privacy divider lower panel | Solid green matte MDF infill panel | |
| Drawer and keyboard tray slides | Cold-rolled steel ball-bearing full-extension slides | |
| Pedestal and CPU stand casters | 50mm diameter black nylon swivel casters, two with locking brakes |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Lockable mobile pedestal | Three-drawer unit on casters with central lock, fits under left work surface | |
|---|---|---|
| Pull-out keyboard tray | Ball-bearing slide mounted under curved central work edge, stows flush when closed | |
| Mobile CPU holder | Wheeled open stand located in central knee well, accommodates standard full-size computer towers | |
| Cable management grommet | Circular grommet on rear work surface routes power and data cables to floor |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Small office reception area | Fits compact entryways for 1 staff member to greet visitors and process paperwork | |
|---|---|---|
| Medical clinic front desk | Provides transaction counter, storage, and computer support for patient check-in |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables, safety and strength requirements for commercial desks | |
|---|---|---|
| EN 14073-2:2004 | Office storage furniture, safety requirements for mobile pedestal units | |
| EN 13722:2004 | Furniture, assessment of surface resistance to abrasion for laminate finishes |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard, static load and durability testing for work surfaces | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard, performance requirements for mobile pedestals |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to panel desk construction | |
|---|---|---|
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable to MFC core panel material | |
| GB 18584-2001 | Formaldehyde emission limits for interior wooden furniture, mandatory for indoor use |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to panel desk construction; 2. GB/T 4897.3-2003: Particleboard for furniture use, applicable to MFC core panel material; 3. GB 18584-2001: Formaldehyde emission limits for interior wooden furniture, mandatory for indoor use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
