Automatic mm / inch conversion · Core engineering specifications
| Overall footprint dimensions | 2800 x 1400 x 1400 mm | |
|---|---|---|
| Standard work surface height | 750 mm | |
| Individual L-desk straight segment length | 1800 mm per outer work surface edge | |
| Work surface depth along straight segments | 750 mm | |
| Curved corner knee opening width | 600 mm | |
| Under-desk seated knee clearance height | 700 mm | |
| Mobile storage pedestal dimensions | 400 x 500 x 600 mm | |
| Partition panel total height | 1400 mm | |
| Upper slotted partition vent section height | 300 mm | |
| Lower solid partition panel height | 1100 mm | |
| Work surface panel thickness | 25 mm | |
| Partition frame profile thickness | 30 mm | |
| Desktop cable grommet diameter | 60 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Uniform distributed work surface static load capacity | 150 kg per workstation | |
|---|---|---|
| Supported user count | 2 seated staff | |
| Product net weight per complete set | 140 kg | |
| Work surface wear resistance rating | 2000 double rubs | |
| Partition panel sound transmission class | 20 dB | |
| Standard commercial warranty period | 5 years | |
| Available finish color options | 12 standard laminate/colors | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface construction | 25mm E1-grade melamine-laminated particleboard with 2mm PVC edge banding | |
|---|---|---|
| Partition frame material | 1.2mm thick powder-coated dark steel rectangular tubing | |
| Lower partition accent panels | 18mm melamine particleboard in sage green finish | |
| Upper slotted partition sections | Powder-coated steel slatted grille with fabric backing | |
| Side modesty panels | 18mm light woodgrain melamine particleboard panels | |
| Mobile pedestal construction | 15mm melamine particleboard carcass with sage green upper drawer front | |
| Pedestal casters | 50mm diameter black nylon swivel casters with lock mechanism | |
| Drawer lock hardware | Keyed-alike cam locks with plastic faceplates | |
| Work surface edge treatment | 2mm thick impact-resistant PVC edge banding on all cut edges | |
| Partition connecting hardware | Zinc-plated steel corner brackets and connector clips | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Knee access design | Curved concave cutout at L-corner to eliminate sharp edge contact during seated use | |
|---|---|---|
| Storage mobility | Each mobile pedestal rolls on 4 lockable casters to reposition under desk or pull out for access | |
| Drawer security | Each pedestal includes a key-locking top drawer to secure personal office valuables | |
| Cable management | Pre-drilled 60mm cable grommet on each work surface to route power and data cords below desk | |
| Modular expandability | Partition frame uses standardized connectors to add adjacent workstations for larger team layouts | |
| Privacy partition function | 1100mm lower solid panel blocks direct seated line of sight between neighboring workstations | |
| Upper partition ventilation | Slotted upper grille section allows air circulation and partial standing visibility without losing seated privacy | |
| Pedestal storage layout | Each mobile pedestal includes 1 shallow stationery drawer and 2 deep file drawers for A4/folio document storage | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Open plan office areas | Divides large open floors into semi-private individual work zones for administrative staff | |
|---|---|---|
| Small business team offices | Fits 2 staff in a compact footprint suitable for 10person startup workspaces | |
| Shared department work zones | Suitable for finance, HR, or operations teams requiring personal storage and quiet work space | |
| Call center cubicle farms | Partition panels reduce cross-talk noise while maintaining supervisor visibility through upper vents | |
| Co-working dedicated desk zones | Fixed allocated workstations with personal locking storage for recurring members | |
| Government/enterprise back-office areas | Commercial-grade construction supports heavy daily use for public sector administrative roles |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable to desk structural performance | |
|---|---|---|
| EN 1335-1:2020 | Office furniture ergonomic dimensions reference for seated work surface and clearance design | |
| EN 1022:2018 | Furniture seating/desk stability testing standard for freestanding office workstations |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard for static load, durability and stability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard for mobile pedestal drawer load and cycle testing |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to laminate work surfaces and storage cabinets | |
|---|---|---|
| GB/T 3327-2017 | Performance standards for office desks and workstations, applicable to structural load and stability | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, minimum E1 grade required for indoor use |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to laminate work surfaces and storage cabinets; 2. GB/T 3327-2017: Performance standards for office desks and workstations, applicable to structural load and stability; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, minimum E1 grade required for indoor use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
