Automatic mm / inch conversion · Core engineering specifications
| Carcass Panel Thickness | 25 mm | |
|---|---|---|
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Desktop uniform static load capacity | 260 kg | |
|---|---|---|
| Partition panel lateral impact resistance | 200 N | |
| Workstation total net weight (assembled) | 280 kg | |
| Recommended user capacity | 4 people | |
| Surface abrasion resistance cycles | 2000 cycles | |
| Standard manufacturer warranty period | 5 years | |
| Available finish color options | 60+ | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop core substrate | E1-grade particle board | |
|---|---|---|
| Worktop surface finish | 0.6mm thick fire-resistant melamine laminate | |
| All panel edge treatment | 2mm thick PVC edge banding | |
| Partition support frames | 1.2mm thick powder-coated aluminum alloy | |
| Upper partition privacy panels | Frosted semi-transparent glass with horizontal stripes | |
| Lower partition solid panels | 1.0mm thick cold-rolled steel with charcoal powder coat | |
| Mobile cabinet drawer and door fronts | Matching light oak melamine-faced MDF | |
| Mobile cabinet structural frame | 0.8mm thick cold-rolled steel | |
| Mobile cabinet casters | 50mm diameter nylon swivel casters, 2 with brake locks | |
| Hardware fittings (locks, slides, connectors) | Commercial-grade zinc-plated steel hardware | |
| Under-desk cable management channels | PVC wiring trays with separated channels | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Cross X modular layout | Divides into 4 independent L-shaped work zones | |
|---|---|---|
| Semi-privacy partition design | 1100mm tall frosted upper panels reduce visual distraction | |
| Integrated cable management system | 60mm desktop grommets feed into under-desk split trays | |
| Mobile per-station storage unit | Rolling cabinet with 1 lockable file drawer, 1 open shelf, 1 hinged door | |
| Lockable storage security | Keyed lock on file drawer secures confidential documents | |
| Modular assembly structure | Pre-drilled panels with knock-down hardware | |
| Brake-equipped casters on storage | 2 lockable swivel casters per cabinet | |
| Customizable configuration support | Adjustable dimensions, partition height and finish colors | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Open-plan office staff zones | Creates dedicated individual workspaces to reduce distraction in open offices | |
|---|---|---|
| Small to medium enterprise offices | Fits 4 employees in a compact footprint for space-efficient office layouts | |
| Call center and back office operations | Provides semi-private work areas with easy team communication across partitions | |
| Shared co-working spaces | Modular design allows reconfiguration for flexible team seating arrangements | |
| Government and corporate administrative departments | Lockable storage supports secure document storage for official work | |
| Temporary project team work areas | Mobile cabinets and modular assembly allow fast deployment for project teams |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Applies to office worktable strength, durability and stability performance requirements | |
|---|---|---|
| EN 1335-1:2020 | Applies to ergonomic dimension coordination for seated office workstations | |
| EN 71-3:2019 | Applies to hazardous substance limits for furniture materials in indoor environments |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Applies to desk/workstation performance and durability testing standards for commercial use | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Applies to storage cabinet structural performance and load testing requirements |
Standards applicable to China-market projects
| GB/T 5237.1-2008 | Applies to aluminum alloy partition frames, defining material composition requirements | |
|---|---|---|
| GB/T 5237.4-2008 | Applies to powder-coated aluminum partition surface performance standards | |
| GB 18580-2017 | Applies to wood-based panel formaldehyde emission limits for indoor furniture | |
| GB/T 3324-2017 | Applies to general technical requirements for wooden office furniture |
This product must meet the following technical requirements: 1. GB/T 5237.1-2008: Applies to aluminum alloy partition frames, defining material composition requirements; 2. GB/T 5237.4-2008: Applies to powder-coated aluminum partition surface performance standards; 3. GB 18580-2017: Applies to wood-based panel formaldehyde emission limits for indoor furniture; 4. GB/T 3324-2017: Applies to general technical requirements for wooden office furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
