Automatic mm / inch conversion · Core engineering specifications
| overall cluster footprint | 2820 x 2820 x 1200 mm | |
|---|---|---|
| standard work surface height | 750 mm | |
| individual workstation desktop size | 1200 x 600 mm | |
| privacy partition total height | 1200 mm | |
| desktop panel thickness | 25 mm | |
| under-desk seated knee clearance height | 650 mm | |
| knee clearance width per position | 600 mm | |
| support leg height | 700 mm | |
| storage drawer front height | 150 mm | |
| pedestal cabinet width per workstation | 400 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| total product net weight | 140 kg | |
|---|---|---|
| uniform desktop static load capacity | 100 kg per seat | |
| surface abrasion resistance | 2000 cycles | |
| design seating capacity | 4 users | |
| product warranty | 5 years | |
| hardware spare parts provision | 5% of total hardware count | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| work surface panels | 25mm E1-class melamine-faced engineered wood, PVC edge banded | |
|---|---|---|
| partition dividers | Perforated mesh upper section, solid sage green fabric lower panel, dark metal frame | |
| support legs | Tapered dark powder-coated steel legs, 1.5mm wall thickness | |
| storage cabinet bodies | 18mm melamine-faced particleboard, light wood grain finish | |
| drawer fronts | 18mm melamine-faced MDF, muted sage green finish, recessed handle cutout | |
| drawer slides | Cold-rolled steel 3-section full extension slides | |
| partition frame hardware | Powder-coated square steel tubing, 30mm x 30mm section | |
| surface finish | Matte melamine laminate, anti-scratch, anti-stain, water-resistant | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| 4-direction individual work zones | Four separated seated positions divided by cross-mounted privacy screens, no shared work surface overlap | |
|---|---|---|
| integrated per-seat storage | Fixed under-desk pedestal per workstation with 1 top shallow drawer and 1 lower storage cabinet for files and supplies | |
| cable management access | Desktop cable grommet per work position, concealed under-desk wire routing channel | |
| privacy screen separation | 1200mm tall dividers block direct sightlines between adjacent seated workers to reduce visual distraction | |
| knock-down modular assembly | Flat-pack CKD construction allows on-site assembly and reconfiguration of cluster layout | |
| leveling adjustment | Glide feet at base of each support leg allow fine height adjustment on uneven office floors | |
| surface damage resistance | Melamine finish resists daily water spills, scuffs and stains from regular office use | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| open plan office work areas | Suitable for corporate open offices requiring individual semi-private workspaces for 4 staff per cluster | |
|---|---|---|
| call center and back-office teams | Ideal for task-focused roles including customer support, data entry, and administrative staff | |
| flexible co-working spaces | Modular construction allows easy reconfiguration to adapt to changing team size and layout needs | |
| startup and small business offices | Space-efficient 4-seat cluster maximizes usable floor area while providing personal storage and privacy for growing teams | |
| standard seated office use | Designed for use with standard ergonomic office chairs at 750mm work height, suitable for 8 hour daily work shifts | |
| indoor dry office environments | Recommended for temperature-controlled indoor office spaces, not for outdoor or high-humidity areas |
EU Market Access Requirements* EN Standards
| office furniture strength and durability | EN 527:2002+A1:2019 | |
|---|---|---|
| office furniture stability | EN 14073:2004 | |
| formaldehyde emission classification | EN 13986:2004+A1:2015 |
US and Canada office-furniture standards
| office desk load performance | ANSI/BIFMA X2021 | |
|---|---|---|
| office storage performance | ANSI/BIFMA X2019 | |
| furniture VOC emissions | ANSI/BIFMA e2019e |
Standards applicable to China-market projects
| desk panel formaldehyde emission | GB/T 17657 | |
|---|---|---|
| office desk structural stability | GB/T 3324 | |
| metal coating adhesion | GB/T 4893.4 |
This product must meet the following technical requirements: 1. desk panel formaldehyde emission: GB/T 17657; 2. office desk structural stability: GB/T 3324; 3. metal coating adhesion: GB/T 4893.4; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
