Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall footprint | 2830 x 2830 x 1200 mm | |
|---|---|---|
| Work surface height | 750 mm | |
| Single L-station arm length | 1200 mm | |
| Work surface depth | 600 mm | |
| Partition panel height | 1200 mm | |
| Partition panel thickness | 30 mm | |
| Worktop thickness | 25 mm | |
| Seated knee clearance height | 650 mm | |
| Mobile pedestal dimensions | 400 x 450 x 600 mm | |
| Cable grommet diameter | 60 mm | |
| Drawer slide extension length | 400 mm | |
| Caster wheel diameter | 50 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Single worktop static load capacity | 91 kg | |
|---|---|---|
| Total workstation assembly weight | 260 kg | |
| Recommended user capacity | 4 people | |
| Finish abrasion resistance | 2000 cycles | |
| Structure service life | 10 years | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Worktop | 25mm high-density particleboard with melamine laminate, 2mm PVC edge banding | |
|---|---|---|
| Support frame | 1.2mm thick powder-coated cold-rolled steel with adjustable leveling feet | |
| Partition panels | Aluminium alloy frame, fabric lower panel, frosted translucent slat upper section | |
| Modesty panels | 18mm thick white melamine-faced particleboard | |
| Mobile pedestals | 18mm melamine-faced particleboard carcass, steel ball-bearing drawer slides, central lock | |
| Hardware components | Zinc-plated steel connecting brackets, corrosion-resistant fasteners |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable management system | Central cable tray under worktop, desktop grommets, in-partition routing channels | |
|---|---|---|
| Mobile pedestal function | 3 lockable drawers, full-extension slides, 360-degree swivel casters, anti-tilt mechanism | |
| Privacy partition function | 1200mm high partial dividers block direct line of sight between seated users | |
| Modular assembly function | Pre-fitted connecting brackets support reconfiguration to alternate cluster layouts |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open plan office areas | Suitable for staff team zones in small to medium office spaces | |
|---|---|---|
| Call center and administrative departments | Partial dividers reduce distraction while maintaining team visibility |
EU Market Access Requirements* EN Standards
| EN 527-2:2002+A1:2019 | Applicable standard for office work tables safety and strength requirements | |
|---|---|---|
| EN 1335-2:2018 | Applicable reference for office furniture stability and structural safety |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Applicable standard for desk products safety and durability performance | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Applicable standard for mobile storage pedestals performance and safety |
Standards applicable to China-market projects
| GB/T 3324-2024 | Applicable standard for general technical requirements of wooden office furniture | |
|---|---|---|
| GB 18580-2017 | Applicable standard for formaldehyde emission limits of wood-based panels | |
| GB/T 35607-2024 | Applicable standard for office furniture durability evaluation |
This product must meet the following technical requirements: 1. GB/T 3324-2024: Applicable standard for general technical requirements of wooden office furniture; 2. GB 18580-2017: Applicable standard for formaldehyde emission limits of wood-based panels; 3. GB/T 35607-2024: Applicable standard for office furniture durability evaluation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
