Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall workstation footprint | 1400 x 700 x 1500 mm | |
|---|---|---|
| Rectangular work surface | 1400 x 700 mm | |
| Finished work surface height | 750 mm | |
| Desktop thickness | 25 mm | |
| Total privacy panel height | 1500 mm | |
| Panel height above work surface | 750 mm | |
| Lower solid modesty panel height | 400 mm | |
| Upper privacy panel visible height | 350 mm | |
| Front knee opening width | 1200 mm | |
| Minimum knee clearance under desktop | 680 mm | |
| Seating entry opening width | 1400 mm | |
| Leveler foot adjustment | 20 mm | |
| Panel frame profile width | 40 mm | |
| Side panel depth | 700 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Desktop static load capacity | 91 kg | |
|---|---|---|
| Uniform desktop distributed load | 150 kg/m2 | |
| Net weight | 62 kg | |
| Single-user capacity | 1 person | |
| Panel connector static stability load | 40 kg per joint | |
| Leveler foot point load | 35 kg per foot | |
| Surface impact acceptance | 2 kg dropped from 150 mm | |
| Recommended daily load distribution | Two 24 in monitors plus 10 kg accessories | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Work surface substrate | 25 mm wood-composite panel | |
|---|---|---|
| Work surface facing | Light wood-look melamine or laminate finish | |
| Impact-resistant desktop edge | PVC or ABS edge banding, 2 mm nominal | |
| Rear and side panel faces | Fabric-covered or laminate panel board | |
| Privacy panel core | Composite board or lightweight honeycomb panel | |
| Partition support frame | Dark gray powder-coated metal or aluminum extrusion | |
| Panel joining hardware | Steel or zinc-alloy corner connectors and rail fasteners | |
| Under-desk support | Dark gray steel vertical legs with horizontal stretcher rail | |
| Leveling feet | Nylon-pad adjustable glides with threaded steel stems | |
| Cable port | Recessed oval plastic desktop cable cover with brush or slide opening | |
| Fastener pack | Zinc-plated steel bolts, cam locks and connecting plates | |
| Surface finish color mix | Pale oak-look top, terracotta lower band, off-white upper band and dark gray frame |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Three-sided privacy arrangement | Rear, left and right panels form a U-shaped visual boundary while the front remains open for entry | |
|---|---|---|
| Seated computer work layout | Single 1400 x 700 mm surface faces the open front with screen panels behind and beside the user | |
| Cable routing | Rear oval desktop port routes monitor and power cables toward the back panel zone | |
| Modular panel connection | Rails, posts and corner connectors allow the screen set to be assembled or reconfigured in straight runs | |
| Leveling adjustment | Threaded glides at exposed feet correct uneven floors without cutting or shimming the panels | |
| Under-desk privacy | Solid lower panels below the work surface conceal the user’s legs from side and rear sight lines | |
| Accessories shown | Laptop, spiral notebook and pen demonstrate writing and notebook-computer use; they are not included furniture hardware | |
| Storage provision | No drawers, pedestal, doors or shelves are integrated into the pictured workstation | |
| Knockdown installation | Desktop, panels, posts, legs and hardware ship separately and assemble with mechanical fasteners | |
| Layout extension | The framed end posts permit linking additional identical stations for project rows when compatible panels are specified | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open-plan office seat | Suitable for individual focused work in call centers, admin floors and accounting departments | |
|---|---|---|
| Temporary project team area | Useful when several identical units are linked into rows for short-term project staffing | |
| School or hospital administration office | Fits computer-based registration, records and clerical tasks requiring one defined workstation | |
| Small private office workstation | Provides an organized single-user desk without consuming space for a full built-in office | |
| Shared hot-desk neighborhood | Can be assigned by shift while maintaining personal visual separation and cable routing | |
| Reception back-office area | Suitable for behind-counter administrative computing rather than public-facing reception service |
EU Market Access Requirements* EN Standards
| EN 527-1 office work tables | Defines safety, strength and dimensional requirements for non-domestic office desks | |
|---|---|---|
| EN 527-2 mechanical safety tests | Provides strength, durability and stability test methods for office work tables | |
| EN 1022 seating and table stability | Useful stability reference when the complete workstation is specified with an office chair | |
| EN 13986 wood-based panels | Covers panel characteristics relevant to desktop and partition board substrates |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5 Desk Products | Recommended strength, durability and structural performance standard for the desktop and frame | |
|---|---|---|
| BIFMA e3 level sustainability criteria | Optional procurement framework for panel, metal and packaging environmental attributes | |
| ANSI/BIFMA X5.9 Storage Accessories | Applicable only if an optional mobile pedestal or storage unit is added | |
| BIFMA G1 ergonomic guideline | Supports checking 750 mm work height with task chair and keyboard equipment |
Standards applicable to China-market projects
| GB/T 3324-2017 general technical requirements | Applies to wooden furniture dimensions, workmanship and inspection of the board work surface | |
|---|---|---|
| GB/T 3325-2017 metal furniture requirements | Applies to metal structural parts, coating integrity and stability requirements | |
| GB 18580-2017 formaldehyde emission | Recommended acceptance basis for wood-based panels used in the desktop and panel cores | |
| GB/T 10357.6-2013 desk static load test | Suggested test method for verifying worktop and support strength | |
| GB/T 10357.7-2013 furniture stability | Suggested basis for evaluating panel-and-leg workstation stability |
This product must meet the following technical requirements: 1. GB/T 3324-2017 general technical requirements: Applies to wooden furniture dimensions, workmanship and inspection of the board work surface; 2. GB/T 3325-2017 metal furniture requirements: Applies to metal structural parts, coating integrity and stability requirements; 3. GB 18580-2017 formaldehyde emission: Recommended acceptance basis for wood-based panels used in the desktop and panel cores; 4. GB/T 10357.6-2013 desk static load test: Suggested test method for verifying worktop and support strength; 5. GB/T 10357.7-2013 furniture stability: Suggested basis for evaluating panel-and-leg workstation stability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
