Single-Seat L-Shaped Modular Office Cubicle Workstation with Louvered Privacy Partitions and Integrated Locking Storage Pedestal (model CUB-L1-LOU-1200) is listed under L-Shaped Office Desk, with overall dimensions of 1500 × 1400 × 1200 mm and main material of Particle‑board (PB). Load capacity: 300 kg. Certifications: modular,structure,louvered,privacy,partition,integrated,locking,storage,cable,grommet,seated,workstation. This page consolidates 6 groups of specifications and GB / EN / ANSI/BIFMA standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall footprint | 1500 x 1400 x 1200 mm | |
|---|---|---|
| Work surface height | 750 mm | |
| Work surface main segment | 1200 x 600 mm | |
| Work surface return segment | 1400 x 450 mm | |
| Seated knee clearance height | 680 mm | |
| Seated knee clearance width | 800 mm | |
| Seated knee clearance depth | 600 mm | |
| Privacy partition total height | 1200 mm | |
| Upper louvered panel height | 300 mm | |
| Lower solid panel height | 900 mm | |
| Partition panel thickness | 83 mm | |
| Worktop thickness | 25 mm | |
| Integrated storage pedestal dimensions | 400 x 600 x 650 mm | |
| Desktop cable grommet diameter | 60 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Desktop static load capacity | 300 kg | |
|---|---|---|
| Pedestal drawer static load | 45 kg | |
| Pedestal shelf static load | 30 kg | |
| Unit net weight | 85 kg | |
| Recommended user weight capacity | 150 kg | |
| Available finish color options | 24 | |
| Surface abrasion resistance | 2000 cycles | |
| Product structural warranty | 10 years | |
| Work surface warranty | 5 years | |
| Reference Static Load | 150 kg depending on category |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Worktop construction | 25mm E1-grade melamine-faced particleboard with 2mm PVC edge banding | |
|---|---|---|
| Partition frame construction | 1.2mm thick powder-coated aluminum alloy modular extrusion frame | |
| Lower partition panel construction | 18mm melamine-faced MDF solid privacy panels with textured grey accent strips | |
| Upper partition panel construction | Translucent frosted PVC horizontal louver slats for light transmission | |
| Storage pedestal construction | 0.8mm thick powder-coated steel cabinet body with integrated cam lock | |
| Hardware components | Zinc-plated steel modular connecting brackets, adjustable floor glides |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable management system | Integrated under-desk aluminum raceway with 60mm desktop grommet for power/data routing | |
|---|---|---|
| Storage security feature | Keyed cam lock securing upper drawer and lower cabinet door on integrated pedestal | |
| Modular connectivity | Pre-drilled connection points on all partition edges for linking to adjacent cubicle units | |
| Adjustable leveling | 10mm height-adjustable floor glides on all partition and frame bases for uneven floors |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open plan office staff work areas | Provides individual seated privacy while enabling modular team layout configuration | |
|---|---|---|
| Administrative and clerical workspaces | Integrated storage and cable management supports daily desk-based task work |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable to work surface | |
|---|---|---|
| EN 1335-1:2020 | Office furniture seating dimensions, used to validate knee clearance compatibility | |
| EN 1022:2018 | Domestic and contract seating stability, applied to workstation structural stability checks |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance standard, applicable to worktop load and durability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage cabinets performance standard, applicable to integrated pedestal testing |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable to worktop and panel components | |
|---|---|---|
| GB/T 3325-2017 | Metal office furniture general technical requirements, applicable to frame and pedestal | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to particleboard/MDF components |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable to worktop and panel components; 2. GB/T 3325-2017: Metal office furniture general technical requirements, applicable to frame and pedestal; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to particleboard/MDF components; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
