Automatic mm / inch conversion · Core engineering specifications
| Primary Component Thickness | 40 mm according to load-bearing role | |
|---|---|---|
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Single worktop static load capacity | 100 kg | |
|---|---|---|
| Set total net weight | 480 kg | |
| Caster rolling load rating | 50 kg per caster | |
| Recommended user weight per station | 150 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Seated user capacity | 6 persons | |
| Product warranty period | 3 years | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface substrate | 25mm E1 grade particleboard | |
|---|---|---|
| Work surface finish | Matte light beige melamine laminate | |
| Partition frame | Silver anodized aluminum alloy extrusion | |
| Lower divider panels | Fabric-wrapped medium density fiberboard | |
| Upper divider slats | Ventilated aluminum louver grille | |
| Mobile pedestal body | 18mm melamine-faced particleboard | |
| Pedestal drawer front | Taupe melamine panel with key lock | |
| Pedestal casters | Black nylon swivel casters, 4 per unit | |
| Partition connecting hardware | Zinc-plated steel brackets and fasteners | |
| Modesty panel under worktop | 18mm matching melamine particleboard | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Modular assembly configuration | Cluster layout configurable into 2/4/6/8 person sets | |
|---|---|---|
| Mobile pedestal storage layout | 1 lockable drawer + 1 open storage compartment per pedestal | |
| Cable management function | One round grommet per work surface for power/data cord routing | |
| Privacy partition function | 1200mm mid-height divider blocks seated cross-desk line of sight | |
| Pedestal mobility function | Four swivel casters allow pedestal to pull out for access or repositioning | |
| Drawers locking function | Individual key lock per pedestal drawer secures personal office supplies | |
| Desk corner design | Curved inner corner on L-shaped worktop eliminates sharp edges for comfortable extended seating | |
| Floor leveling function | Adjustable glide feet on fixed partition legs compensate for uneven office floors | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Number of shipping cartons | 18 cartons | |
|---|---|---|
| Largest shipping carton size | 1450 x 1250 x 80 mm | |
| Total shipping gross weight | 540 kg | |
| Total shipment volume | 2.6 CBM | |
| Assembly time for 2-person team | 240 minutes | |
| 40ft HQ container loading quantity | 18 sets | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Open plan corporate offices | Provides individual semi-private workstations in shared collaborative office spaces | |
|---|---|---|
| Co-working space shared offices | Modular configuration adapts to changing team sizes and flexible seating plans | |
| Call center operation floors | Separated workstations reduce acoustic and visual distraction for staff on calls | |
| Government administrative offices | Durable commercial construction supports daily high-traffic long-term use | |
| Startup open work areas | Cost-effective cluster layout maximizes seat count within limited floor space | |
| Training and temporary office setups | Mobile pedestals and modular frames support fast rearrangement for event use |
EU Market Access Requirements* EN Standards
| Office furniture strength standard | EN 527:2002+A1:2019 | |
|---|---|---|
| Office furniture stability standard | EN 14073:2004 | |
| Office ergonomics standard | EN 527:2011 |
US and Canada office-furniture standards
| Office desk performance standard | ANSI/BIFMA X2021 | |
|---|---|---|
| Mobile storage standard | ANSI/BIFMA X2019 |
Standards applicable to China-market projects
| Office desk dimensional standard | GB/T 3326 | |
|---|---|---|
| Formaldehyde emission standard | GB 18580 | |
| Furniture surface durability standard | GB/T 4893.8 | |
| Hardware performance standard | GB/T 13668 |
This product must meet the following technical requirements: 1. Office desk dimensional standard: GB/T 3326; 2. Formaldehyde emission standard: GB 18580; 3. Furniture surface durability standard: GB/T 4893.8; 4. Hardware performance standard: GB/T 13668; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
