Automatic mm / inch conversion · Core engineering specifications
| Overall workstation dimensions (2-person unit) | 2800 x 1600 x 1200 mm | |
|---|---|---|
| Single L-shaped work surface dimensions | 1400 x 1200 x 750 mm | |
| Privacy partition height above work surface | 450 mm | |
| Work surface thickness | 25 mm | |
| Knee clearance height under work surface | 650 mm | |
| Knee clearance width at central opening | 600 mm | |
| Fabric partition panel thickness | 83 mm | |
| Under-desk pedestal dimensions | 400 x 550 x 650 mm | |
| Desktop cable grommet diameter | 60 mm | |
| Tapered metal leg height | 100 mm | |
| Pedestal drawer front height | 150 mm | |
| Edge banding thickness | 2 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Per-workstation static load capacity | 300 kg | |
|---|---|---|
| Drawer slide static load rating | 25 kg | |
| Drawer slide cycle durability | 50000 cycles | |
| Workstation net weight (single station) | 120 kg | |
| Recommended maximum user weight per station | 136 kg | |
| Surface abrasion resistance rating | 2000 cycles | |
| Manufacturer warranty period | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface substrate | E1-grade melamine-faced particle board | |
|---|---|---|
| Privacy divider panels | Beige woven fabric over fiberboard core | |
| Partition frame system | Powder-coated aluminum extrusions | |
| Support legs | Powder-coated tapered steel legs | |
| Edge banding | 2mm thick impact-resistant PVC | |
| Pedestal cabinet body | Melamine-laminated particle board | |
| Drawer front accent panel | Fabric-wrapped panel | |
| Drawer hardware | Zinc alloy pull handles and steel ball-bearing slides | |
| Cable management components | ABS plastic grommets and under-desk raceways | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Seated visual privacy | 450mm high fabric dividers block direct line of sight between adjacent users | |
|---|---|---|
| Integrated under-desk storage | Each station includes 1 open upper shelf, 1 lockable drawer, 1 lower cabinet door | |
| Modular reconfiguration | Aluminum connector system allows rearrangement into linear, L, or U-shaped layouts | |
| Integrated cable management | Surface grommets and under-desk raceways route power and data cables away from leg space | |
| Elevated base design | 100mm leg clearance under desk and pedestals allows easy floor cleaning | |
| Tackable divider surface | Fabric panel surface accepts push pins for posting notes, schedules, or documents | |
| Lockable storage drawer | Central pedestal drawer includes keyed lock to secure personal valuables or confidential documents | |
| Scratch-resistant work surface | Melamine laminate resists scuffs from keyboards, mice, and office equipment | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open-plan office work areas | Provides individual partitioned workspaces for 2 staff while retaining collaborative space access | |
|---|---|---|
| Small business or startup offices | Space-efficient L-shaped layout fits compact floor plans without dedicated private offices | |
| Call center or administrative departments | Balances visual privacy with supervisor visibility for task-focused work | |
| Temporary or flexible office fit-outs | Modular design allows reconfiguration as team size or layout needs change | |
| Co-working space dedicated desks | Fixed assigned workstations with personal storage for regular co-working members | |
| Back-office support areas | Durable commercial-grade construction suited for daily 8+ hour use by administrative staff |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables, safety and strength requirements for commercial workstation design | |
|---|---|---|
| EN 1335-1:2020 | Office work chair dimensional compatibility to ensure proper knee clearance fit | |
| EN 14073-2:2004 | Office storage furniture, safety requirements for under-desk pedestal units |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard, applicable for work surface load and durability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard, applicable for pedestal drawer slide and lock performance |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk structural stability | |
|---|---|---|
| GB/T 4897.3-2015 | Requirements for particle board used in furniture for load-bearing work surfaces | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, E1 grade compliance for indoor use |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk structural stability; 2. GB/T 4897.3-2015: Requirements for particle board used in furniture for load-bearing work surfaces; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, E1 grade compliance for indoor use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
