Automatic mm / inch conversion · Core engineering specifications
| Overall cluster dimensions | 4200 x 1200 x 1200 mm | |
|---|---|---|
| Worksurface height | 750 mm | |
| Per-seat L-side worktop length | 1600 mm | |
| Worksurface depth | 700 mm | |
| Desktop thickness | 25 mm | |
| Partial partition height | 1200 mm | |
| Partition panel thickness | 60 mm | |
| Seated knee clearance height | 650 mm | |
| Mobile pedestal dimensions | 400 x 500 x 600 mm | |
| PVC edge banding thickness | 2 mm | |
| Partition frame profile thickness | 1.2 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Total workstation unit weight | 285 kg | |
|---|---|---|
| Static uniform worktop load capacity | 150 kg | |
| Pedestal drawer static load per drawer | 25 kg | |
| Recommended user capacity | 3 people | |
| Surface scratch resistance | 2000 cycles | |
| Drawer slide durability | 50000 open/close cycles | |
| Caster rolling durability for pedestals | 20000 travel cycles | |
| Warranty period | 8 years | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worksurface core | E1 grade particleboard | |
|---|---|---|
| Worksurface finish | Light wood grain melamine laminate | |
| Worksurface edging | 2mm thick PVC edge banding | |
| Partition panel surface | Sage green fabric wrap over MDF core | |
| Partition frame | Powder-coated aluminum alloy profile | |
| Mobile pedestal body | Light wood grain melamine-faced particleboard | |
| Pedestal drawer front | Sage green melamine panel with key lock | |
| Pedestal casters | Black nylon swivel casters, 2 with lock | |
| Structural support legs | Powder-coated square steel tubing | |
| Hardware components | Zinc-plated steel screws, connectors and lock cylinders | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Modular connection system | Aluminum profile slot connectors for reconfigurable cluster layouts | |
|---|---|---|
| Mobile pedestal storage | 3 lockable drawers per seat, rolling for flexible under-desk placement | |
| Cable management | Desktop cable grommets + under-desk cable trays for concealed power/data routing | |
| Partition privacy function | 1200mm high panels block seated line of sight between adjacent work positions | |
| Curved worktop design | Rounded inner L-corner to maximize usable desk surface and reduce sharp edge contact | |
| Pedestal caster lock | 2 locking casters per pedestal to fix unit position during use | |
| Partition accessory mounting | Horizontal aluminum slots for hanging monitor arms, document holders or desk organizers | |
| Drawer lock function | Keyed alike drawer lock per pedestal to secure personal work documents and supplies | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Open plan office staff areas | Designed for high-density team work with partial visual privacy between seats | |
|---|---|---|
| Small to medium enterprise work zones | Clustered layout optimizes floor space for 3 employees per cluster unit | |
| Call center and administrative offices | Low partitions allow team communication while reducing cross-seat distraction | |
| Hot-desking shared workspaces | Standard dimensions and modular design support flexible shared work arrangements | |
| Startup and co-working spaces | Matching light wood and green finish fits modern casual office aesthetic | |
| Back-office administrative departments | Integrated lockable storage provides secure personal space per employee |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable to worktop load and stability | |
|---|---|---|
| EN 1335-1:2020 | Office furniture ergonomic clearance requirements for seated work positions | |
| EN 1022:2018 | Furniture seating and table stability testing, applicable to desk structure stability | |
| EN 717-1:2004 | Formaldehyde emission testing for wood-based panels, applicable to substrate emissions |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for strength, durability and structural stability | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard for pedestal drawer load and slide durability | |
| ANSI/BIFMA M7.1-2020 | Standard test method for formaldehyde emissions from office furniture |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable to desk top and pedestal construction | |
|---|---|---|
| GB/T 3327-2017 | Technical requirements for office desks, applicable to worksurface dimensions and load performance | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to particleboard substrate compliance | |
| GB/T 4897.3-2003 | Requirements for particleboard used in furniture, applicable to desk core material |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable to desk top and pedestal construction; 2. GB/T 3327-2017: Technical requirements for office desks, applicable to worksurface dimensions and load performance; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to particleboard substrate compliance; 4. GB/T 4897.3-2003: Requirements for particleboard used in furniture, applicable to desk core material; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
