Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall footprint | 3200 x 762 x 1580 mm | |
|---|---|---|
| Individual work surface | 1400 x 600 x 25 mm | |
| Finished desk height | 762 mm | |
| Knee clearance opening | 620 x 500 x 690 mm | |
| Knee clearance height under top | 670 mm | |
| Privacy screen height above work surface | 520 mm | |
| Privacy screen panel thickness | 41 mm | |
| Center divider cabinet | 400 x 700 x 1180 mm | |
| End storage cabinet | 400 x 700 x 1180 mm | |
| Open CPU compartment | 360 x 520 x 620 mm | |
| Front modesty panel | 1200 x 450 x 25 mm | |
| Cable grommet diameter | 60 mm | |
| Leveling foot diameter | 35 mm | |
| Square support leg section | 44 x 44 mm | |
| PVC edge band thickness | 2 mm | |
| Finished Top Thickness | 50 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Static load per work surface | 113 kg | |
|---|---|---|
| Combined desktop static capacity | 226 kg | |
| CPU shelf static capacity | 25 kg | |
| Product net weight | 160 kg | |
| Supported users | 2 seated reception or administrative staff | |
| Cable tray distributed capacity | 10 kg | |
| Leveling adjustment range | 12 mm | |
| Commercial warranty target | 60 months | |
| Available colorways in this configuration | 2 finishes | |
| Laminate surface durability target | 100000 abrasion cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Work surfaces | 25 mm thermally fused laminate over engineered-wood core | |
|---|---|---|
| Surface edging | 2 mm PVC edge banding with rounded impact edges | |
| Front modesty panels | 25 mm gray laminate engineered-wood panels | |
| Center and end cabinets | Gray melamine-faced engineered-wood board with matching shelf boards | |
| Privacy screen frames | Black powder-coated steel or aluminum rectangular framework | |
| Horizontal privacy infill | Rigid translucent slatted panels with black horizontal rails | |
| CPU compartment hardware | Adjustable metal shelf supports with pre-punched side slots | |
| Structural support legs | 44 mm square powder-coated steel legs with base connectors | |
| Leveling feet | Glass-filled nylon round pads with threaded steel stems | |
| Cable grommets | Molded plastic cable port with removable cover and brush-style opening | |
| Panel joining hardware | Cam locks, connector bolts, and steel corner brackets | |
| Internal panel substrate | 18 mm engineered-wood board with laminate or melamine faces |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Two independent seated work positions | Each 1400 mm surface has a separate knee bay, cable port, and modesty panel | |
|---|---|---|
| Visitor-facing privacy screening | A 520 mm high slatted screen separates staff from the rear or visitor side | |
| Central visual division | The 1180 mm center cabinet divides users while retaining side equipment access | |
| Desktop cable routing | A 60 mm grommet in each surface routes monitor and power cables below | |
| Under-desk cable management | Vertical channels and an under-top tray carry cables to the equipment bays | |
| CPU and equipment storage | Two open bays provide floor access, ventilation, and cable pass-through for tower CPUs | |
| Adjustable equipment shelf | Side-mounted support slots allow 3 shelf-height positions in each open bay | |
| Modular field assembly | Desk modules, divider cabinets, end panels, and screens join on site with knockdown hardware | |
| Floor leveling | Threaded feet compensate for floor irregularity and protect floor finishes | |
| Linear extension capability | Matching connector points allow additional workstation modules to be joined in a row | |
| Cable and power access in CPU bay | A circular base opening lets power and network cables enter the equipment compartment | |
| Front modesty coverage | The 450 mm high solid panel conceals legs and under-desk equipment from visitors |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Corporate reception area | Suitable for two staff handling visitor sign-in, calls, badges, and appointment checks | |
|---|---|---|
| Open-plan administrative cluster | Fits a linear back-office zone where two users require visual separation and cable control | |
| Service counter support station | Works behind a customer-service counter for document processing and equipment storage | |
| Medical or educational administration office | Supports two receptionists managing records, scheduling, and visitor inquiries | |
| Hotel or membership lobby | Provides two coordinated check-in or concierge positions with a consistent gray and walnut finish | |
| Shared public-sector service hall | Can be repeated in a row to create multiple intake windows | |
| Recommended companion seating | Pair with armless task chairs having a 520 mm adjustable seat height | |
| Power and data planning | Place floor or wall outlets within 1000 mm of each CPU bay for clean cable routing |
EU Market Access Requirements* EN Standards
| EN 527-1 applicability | Use for office work table safety, dimensions, and mechanical strength requirements | |
|---|---|---|
| EN 527-2 applicability | Use for office work table mechanical safety test methods | |
| EN 15372 applicability | Use for durability, strength, and stability requirements for non-domestic storage furniture | |
| EN 717-1 applicability | Use for formaldehyde release classification of wood-based panels | |
| EN 1022 applicability | Use for seating-independent stability assessment where fixed storage panels influence tipping |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5 applicability | Use for desk products strength, load, fatigue, and stability acceptance | |
|---|---|---|
| ANSI/BIFMA X5.9 applicability | Use for storage units strength, drawer or shelf performance, and stability checks | |
| BIFMA E3 applicability | Use as a multi-attribute sustainability framework for materials, energy, and social criteria |
Standards applicable to China-market projects
| GB/T 3324 applicability | Use for wooden furniture dimensions, tolerances, and inspection of laminate desk components | |
|---|---|---|
| GB/T 3325 applicability | Use for metal furniture structural requirements and coated steel support framing | |
| GB 18580 applicability | Use for formaldehyde emission limits of engineered-wood boards | |
| GB/T 4893 applicability | Use for furniture surface tests including abrasion, impact, and liquid resistance | |
| GB/T 10357 applicability | Use for furniture mechanical strength and stability test methods |
This product must meet the following technical requirements: 1. GB/T 3324 applicability: Use for wooden furniture dimensions, tolerances, and inspection of laminate desk components; 2. GB/T 3325 applicability: Use for metal furniture structural requirements and coated steel support framing; 3. GB 18580 applicability: Use for formaldehyde emission limits of engineered-wood boards; 4. GB/T 4893 applicability: Use for furniture surface tests including abrasion, impact, and liquid resistance; 5. GB/T 10357 applicability: Use for furniture mechanical strength and stability test methods; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
