4-Person Cross-Shaped L-Shape Modular Office Workstation Cluster with Low Dividers and Storage Pedestals (model WS-CR4-L-OAKWHT-01) is listed under L-Shaped Office Desk, with overall dimensions of 2800 × 2800 × 1150 mm and main material of Particle‑board (PB). Load capacity: 91 kg. Certifications: Two-tone,oak/white,finish,low-partition,cross,layout,4-person,L-shape,workstations,lockable,drawer,pedestals. This page consolidates 6 groups of specifications and GB / EN / ANSI/BIFMA standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall assembled footprint | 2800 x 2800 x 1150 mm | |
|---|---|---|
| Standard desk surface height | 750 mm | |
| Individual L-workstation straight section width | 1400 mm | |
| Individual L-workstation return section width | 1200 mm | |
| Work surface depth | 600 mm | |
| Privacy divider height above desk | 400 mm | |
| Divider panel thickness | 25 mm | |
| Work surface thickness | 25 mm | |
| Knee clearance height under desk | 670 mm | |
| Knee clearance width per position | 700 mm | |
| Per-user storage pedestal dimensions | 400 x 500 x 650 mm | |
| PVC edge band thickness | 2 mm | |
| Cable grommet diameter | 80 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Per-workstation static surface load capacity | 91 kg | |
|---|---|---|
| Drawer slide cycle rating | 50000 cycles | |
| Adjustable foot height adjustment range | 15 mm | |
| Surface finish abrasion resistance | 2000 cycles | |
| Indicative total assembled product weight | 320 kg | |
| Recommended user weight limit per station | 136 kg | |
| Structural frame warranty | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Work surface | 25 mm E0-grade melamine-faced particleboard with 2 mm PVC edge | |
|---|---|---|
| Privacy dividers | 25 mm rigid composite panel with white matte finish and lower oak trim | |
| Support frame and legs | Powder-coated square steel tubing with adjustable leveling feet | |
| Storage pedestals | 18 mm melamine-faced composite board with lockable steel drawer slides | |
| Hardware components | Zinc-plated steel connecting bolts, cam locks, and keyed drawer locks | |
| Cable management components | ABS plastic cable grommets and under-desk cable trays |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Workspace privacy separation | Low 400 mm dividers create 4 dedicated individual L-shaped work zones | |
|---|---|---|
| Per-user integrated storage | Three-drawer pedestal per station holds stationery and letter/legal files | |
| Cable routing system | Desk grommets and under-desk trays organize power and data cables | |
| Floor leveling adjustment | Adjustable steel feet compensate for uneven floors to stabilize surfaces |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open-plan corporate office space | Suitable for 4 staff in teams, departments, or call center operations | |
|---|---|---|
| Startup or co-working flexible work areas | Supports reconfigurable team seating for project-based work groups |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and dimensional requirements, applicable to desk surfaces | |
|---|---|---|
| EN 527-2:2002+A1:2019 | Office worktables mechanical safety and strength requirements, applicable for load testing | |
| EN 1335-1:2020 | Office chair dimensional and safety coordination, applies to chair under-desk clearance | |
| EN 14073-2:2004 | Office storage furniture safety and strength, applies to drawer pedestals |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products performance and safety standard, applicable for structural testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard, applicable for pedestal drawer performance | |
| ANSI/BIFMA X7.1-2021 | Formaldehyde emission standard for low-emitting office furniture |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable to composite desk components | |
|---|---|---|
| GB/T 3327-2017 | Performance test methods for office desks and workstations, applicable for stability and load testing | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to composite board materials | |
| GB/T 4897.3-2003 | Particleboard specifications for furniture use, applicable to desktop and cabinet substrates |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable to composite desk components; 2. GB/T 3327-2017: Performance test methods for office desks and workstations, applicable for stability and load testing; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to composite board materials; 4. GB/T 4897.3-2003: Particleboard specifications for furniture use, applicable to desktop and cabinet substrates; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
