Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Finished Top Thickness | 50 mm | |
|---|---|---|
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Recommended occupants | 1 person per L-shaped work position | |
|---|---|---|
| Desktop static load | 113 kg | |
| Drawer slide load rating | 25 kg per drawer | |
| Drawer slide cycle rating | 50,000 cycles | |
| Door hinge cycle rating | 100,000 cycles | |
| Open shelf load | 20 kg per shelf | |
| Cable tray distributed load | 10 kg | |
| Leveling adjustment range | 15 mm | |
| Recommended finished-floor desk load | 6.5 kN/m² | |
| Worktop static load | 113 kg uniformly distributed over the desktop |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Worktop substrate and facing | 25 mm melamine-faced engineered wood board with commercial office laminate surface | |
|---|---|---|
| Worktop edge protection | 2 mm PVC edge banding bonded around exposed worktop edges | |
| Storage cabinet panels | 18 mm melamine-faced particleboard or MDF panels with white and light-oak visible faces | |
| Terracotta accent panels | Matte terracotta-brown melamine-finished engineered wood panels on shelf backs and screen modesty sections | |
| Translucent privacy screen | Ribbed or slatted translucent panel set inside a dark rectangular perimeter frame | |
| Privacy screen frame | Dark gray aluminum or powder-coated metal extruded frame with vertical connecting posts | |
| Lower solid divider panels | White and terracotta composite panels housed within the dark metal screen frame | |
| Drawer and door hardware | Metal key lock, concealed drawer runners, cabinet hinges, and pull-free flush front design | |
| Support and leveling system | Cylindrical white polymer or metal-capped leveling feet under cabinet modules | |
| Internal cable channel | Separated under-work surface channel for power and data cables with outlet faceplates | |
| Power and data faceplates | Two vertical outlet plates with multiple socket positions mounted under the work surface | |
| Storage cabinet carcass | 18 mm melamine-faced engineered wood panels with glued and doweled cabinet construction |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| L-shaped work layout | Corner configuration provides a straight main task surface and perpendicular return for writing, printing, or reference materials | |
|---|---|---|
| Privacy separation | 1200 mm high framed screens block direct sight lines while the translucent upper section retains daylight transmission | |
| Integrated personal storage | Left pedestal combines one lockable shallow drawer, one lower door, and adjacent open shelving for daily office materials | |
| Overhead storage bridge | Rear upper cabinet and open shelf modules store binders above shoulder height without occupying knee space | |
| Cable routing from desktop | 80 mm rear grommet directs monitor and device cables from the work surface into the under-desk channel | |
| Power and data segregation | Underside duct separates low-voltage data cables from power leads and presents outlets near the knee-bay side panel | |
| Equipment compartment | Closed lower bay provides CPU or personal storage space with a 60 mm cable pass-through at the base | |
| Locking control | Keyed drawer lock secures the top drawer; keyed-alike or master-key suite must be specified at order | |
| Floor leveling | Individual adjustable feet compensate for carpet or uneven floor slabs and keep panels aligned during connection | |
| Modular cluster expansion | Panel posts and flush side frames allow additional workstations to connect in runs or clustered bench arrangements | |
| Fixed-height working position | 750 mm work height is designed for fixed seated office use with a standard task chair | |
| Door and drawer access | Flush-front storage doors and drawers open into the user side, preserving the outer privacy-screen face |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open-plan office seat | Suitable for one knowledge worker who needs privacy, computer space, and personal storage in a dense office | |
|---|---|---|
| Administrative workstation | Configured for paperwork, phone, printer, and reference binders using the return and overhead shelves | |
| Finance or HR position | Lockable drawer and enclosed lower storage suit confidential files and personal office materials | |
| IT or technical support seat | Under-desk CPU bay, grommet, and divided cable duct support desktop equipment and multiple data leads | |
| Cluster deployment | Multiple units can connect through 60 mm divider posts to form teams, rows, or departmental clusters | |
| Project-based office | Recommended where power/data outlets and storage must be installed without separate loose cabinets | |
| Managerial open workstation | Provides higher privacy and storage than a basic bench desk while retaining a collaborative open-office layout |
EU Market Access Requirements* EN Standards
| EN 527-1:2011+A1:2019 | Office worktables safety, strength, and durability requirements applicable to desk surfaces and supports | |
|---|---|---|
| EN 16139:2013+A1:2021 | Applicable standards and test results require confirmation |
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical specification for wooden furniture, applicable to dimensional accuracy, edge finishing, and cabinet workmanship inspection | |
|---|---|---|
| GB/T 3325-2017 | Metal furniture general technical requirements, applicable to metal screen frames, supports, and coating inspection | |
| GB 18580-2017 | Formaldehyde emission control for wood-based panels, recommended acceptance limit for indoor workstation panels | |
| GB/T 10357 furniture strength tests | Desk and storage strength, stability, and durability test methods should be used for load and safety verification | |
| GB/T 33718-2017 | Safety and technical requirements for office furniture screens and workstation partitions |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical specification for wooden furniture, applicable to dimensional accuracy, edge finishing, and cabinet workmanship inspection; 2. GB/T 3325-2017: Metal furniture general technical requirements, applicable to metal screen frames, supports, and coating inspection; 3. GB 18580-2017: Formaldehyde emission control for wood-based panels, recommended acceptance limit for indoor workstation panels; 4. GB/T 10357 furniture strength tests: Desk and storage strength, stability, and durability test methods should be used for load and safety verification; 5. GB/T 33718-2017: Safety and technical requirements for office furniture screens and workstation partitions; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
