Automatic mm / inch conversion · Core engineering specifications
| Overall unit dimensions | 3302 x 1651 x 1200 mm | |
|---|---|---|
| Per-seat L-shaped desktop dimensions | 1651 x 1651 mm | |
| Work surface height | 750 mm | |
| Desktop thickness | 25 mm | |
| PVC edge banding thickness | 2 mm | |
| Privacy partition height | 1200 mm | |
| Partition panel thickness | 40 mm | |
| Integrated under-desk pedestal dimensions | 600 x 550 x 725 mm | |
| Seated knee clearance under desktop | 620 mm | |
| Knee opening width at seat position | 800 mm | |
| Cable grommet diameter | 60 mm | |
| Support leg height (pedestal base to floor) | 125 mm | |
| Storage partition panel thickness (cabinet) | 18 mm | |
| Drawer internal usable depth | 450 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat |
Net weight / load capacity / users / durability
| Uniform desktop static load capacity | 100 kg | |
|---|---|---|
| Drawer slide open/close cycle life | 50000 cycles | |
| Cabinet hinge open/close cycle life | 80000 cycles | |
| Surface abrasion resistance | 30 rpm wear rating | |
| Surface light fastness rating | Grade 4 | |
| Recommended maximum user weight per seat | 110 kg | |
| Commercial product warranty | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop panel | 25mm melamine-faced MFC panel, scratch and water resistant | |
|---|---|---|
| Privacy partition frame | Powder-coated extruded aluminum profile, corrosion resistant | |
| Partition upper panel | Tensioned woven mesh fabric over rigid core, allows partial airflow | |
| Partition lower panel | Solid fabric-covered tackable board, blocks lower line of sight | |
| Under-desk pedestal panels | 18mm melamine-faced engineered wood, matching desktop finish | |
| Drawer and cabinet hardware | Zinc alloy lock core, chrome-finished steel hinges, 3-section ball-bearing slides | |
| Support legs | Powder-coated tapered steel legs with adjustable leveler feet | |
| Edge banding | 2mm thick PVC rounded edge banding, impact and water resistant | |
| Cabinet handle | Integrated recessed pull on drawer and cabinet door, matte gray finish | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Privacy partition layout | 3-sided dividers per seat separate adjacent workstations for seated visual privacy | |
|---|---|---|
| Under-desk pedestal storage | Upper open supply shelf, middle lockable drawer, lower closed cabinet door for personal storage | |
| Cable management system | Desktop cable grommet routes cords to under-desk cable tray for power and data cables | |
| Leveler adjustment | Adjustable feet on support legs and partition bases compensate for uneven floor surfaces | |
| Lock mechanism | Central linked lock secures drawer and cabinet door with a single key for security | |
| Modular connectivity | Pre-drilled connection points allow linking multiple cubicle units into larger workstation banks | |
| Drawer slide operation | Full-extension 3-section ball-bearing slides allow full access to drawer contents without tipping | |
| Quiet operation | Soft-close drawer slides and hinges reduce noise in open office environments | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open plan office staff areas | Suitable for dense team workspaces providing individual seated visual privacy | |
|---|---|---|
| Small business administrative offices | Provides dedicated work surfaces and locked personal storage for permanent staff | |
| Co-working shared office spaces | Easily reconfigurable modular layout adapts to changing team size requirements | |
| Call center and customer service floors | Acoustic and visual separation reduces distraction between adjacent agents | |
| Government and corporate back-office work areas | Durable commercial-grade construction withstands daily high-traffic use | |
| Startup office fit-out projects | Neutral beige and gray color scheme matches most modern office interior palettes |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Applicable standard for office work desk dimensions, strength and stability requirements | |
|---|---|---|
| EN 1335-1:2020 | Applicable reference standard for seated office workstation clearance dimensions | |
| EN 12521:2015 | Applicable durability and safety standard for commercial office furniture |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Applicable performance standard for desk static load, cycle and stability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Applicable performance standard for office storage pedestals and drawer units |
Standards applicable to China-market projects
| GB 18580-2017 | Applicable standard for formaldehyde emission limits for wood-based panels, E1 grade ≤0.124mg/m³ | |
|---|---|---|
| GB/T 3324-2017 | Applicable general technical requirement standard for wooden office furniture | |
| GB/T 10357.1-2013 | Applicable test standard for desk surface static load and mechanical stability |
This product must meet the following technical requirements: 1. GB 18580-2017: Applicable standard for formaldehyde emission limits for wood-based panels, E1 grade ≤0.124mg/m³; 2. GB/T 3324-2017: Applicable general technical requirement standard for wooden office furniture; 3. GB/T 10357.1-2013: Applicable test standard for desk surface static load and mechanical stability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
