| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall workstation dimensions | 2800 x 2400 x 1200 mm | |
|---|---|---|
| Work surface height | 750 mm | |
| Individual L-worktop segment size | 1400 x 600 mm per straight section, 1000 x 600 mm per return | |
| Partition panel thickness | 45 mm | |
| Partition lower fabric panel height | 300 mm | |
| Partition upper slatted translucent section height | 900 mm | |
| Knee clearance height under work surface | 673 mm | |
| Curved front knee cutout radius | 300 mm | |
| Desktop cable grommet diameter | 60 mm | |
| Mobile CPU trolley clearance | 350 mm | |
| Caster diameter for CPU trolleys | 50 mm | |
| Work surface thickness | 25 mm | |
| ABS edge banding thickness | 2 mm | |
| Square steel leg profile | 45 x 45 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Uniform desktop static load capacity | 113 kg | |
|---|---|---|
| Drawer slide cycle life | 50000 open/close cycles | |
| Recommended user weight capacity per station | 136 kg | |
| Partition sound transmission class | 18 | |
| Total workstation shipping weight | 201 kg | |
| Warranty period | 5 years | |
| Available color options | 6 | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Work surface | 25mm melamine-faced chipboard with 2mm ABS edge banding, scratch-resistant finish | |
|---|---|---|
| Partition frame | Powder-coated aluminum extrusion with modular corner connectors | |
| Partition lower panel | Fabric-upholstered 16mm hardboard in muted green finish | |
| Partition upper panel | Translucent horizontal slatted polycarbonate insert for light transmission | |
| Support frame and modesty panel | 16mm melamine panel and 45mm square powder-coated steel legs with adjustable levelers | |
| Storage pedestal and CPU trolley | 16mm melamine carcass with steel ball-bearing slides, keyed lock, 50mm nylon casters |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Privacy partition | 1200mm tall panels divide adjacent workspaces while allowing overhead light transmission | |
|---|---|---|
| Storage system | Fixed outer pedestal includes 1 lockable drawer and 1 cabinet door per position with linked key lock | |
| CPU support | Rolling under-desk caster trolley holds computer tower with 2 locking casters for position stability | |
| Cable management | Round desktop grommet routes power/data cables to under-desk raceways for clutter-free work surface |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open-plan office staff areas | Provides seated privacy and dedicated storage for two employees in high-density workspace layouts | |
|---|---|---|
| Call center and customer service zones | Modular L-layout supports multi-station expansion with integrated cable routing for phone and IT equipment |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables: safety, strength and durability requirements for commercial workstations | |
|---|---|---|
| EN 1335-1:2020 | Office furniture: seating dimensional and performance reference for workstation compatibility | |
| EN 1022:2018 | Domestic and contract furniture seating stability test standard for task chair use at workstations |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products: standard for safety, durability and structural performance of office work surfaces | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units: performance standard for lockable pedestals and drawer slide durability | |
| ANSI/BIFMA e3-2019 | Furniture sustainability standard for low-emission materials and indoor air quality compliance |
Standards applicable to China-market projects
| GB 18580-2017 | Formaldehyde emission limit ≤0.124mg/m³ for engineered wood panels used in indoor office furniture | |
|---|---|---|
| GB/T 3324-2017 | General technical requirements for wooden office furniture, including dimensional stability and edge bonding strength | |
| GB/T 10357.1-2013 | Desk static load and durability test methods for work surface and structural frame performance |
This product must meet the following technical requirements: 1. GB 18580-2017: Formaldehyde emission limit ≤0.124mg/m³ for engineered wood panels used in indoor office furniture; 2. GB/T 3324-2017: General technical requirements for wooden office furniture, including dimensional stability and edge bonding strength; 3. GB/T 10357.1-2013: Desk static load and durability test methods for work surface and structural frame performance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
