Automatic mm / inch conversion · Core engineering specifications
| Overall unit dimensions | 1600 x 1600 x 1200 mm | |
|---|---|---|
| Work surface height above floor | 750 mm | |
| Work surface thickness | 25 mm | |
| Work surface depth | 700 mm | |
| Partition panel thickness | 83 mm | |
| Under-desk knee clearance height | 680 mm | |
| Under-desk knee clearance width | 1100 mm | |
| Storage pedestal width | 400 mm | |
| Storage pedestal depth | 550 mm | |
| Storage pedestal total height | 1200 mm | |
| CPU bay dimensions | 300 x 500 x 450 mm | |
| Cable grommet diameter | 60 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Work surface uniform static load | 91 kg | |
|---|---|---|
| Single drawer static load | 15 kg | |
| Open shelf static load per level | 20 kg | |
| Drawer slide cycle rating | 50000 operations | |
| Total unit net weight | 100 kg | |
| Seating capacity per station | 1 person | |
| Partition surface tackability | Yes | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface | 25mm E1 grade melamine-faced particleboard with 2mm PVC edge | |
|---|---|---|
| Storage cabinet carcass | 18mm E1 grade white melamine particleboard | |
| Storage door/drawer fronts | 18mm light wood finish melamine particleboard | |
| Partition framing | 1.2mm thick powder-coated gray aluminum extrusions | |
| Upper partition panels | 5mm semi-transparent frosted slatted acrylic | |
| Lower partition panels | 18mm light wood finish melamine particleboard | |
| Drawer hardware | Cold-rolled steel 3-section ball-bearing slides | |
| Lock mechanism | Zinc alloy keyed cam lock with 2 keys per unit | |
| Adjustable foot pads | Nylon base with 10mm height adjustment thread | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Cable management | 60mm desk grommet + under-desk cable pass-through in CPU bay | |
|---|---|---|
| Drawer operation | Full-extension ball-bearing slides with soft-close damping | |
| Storage locking | Keyed lock secures upper drawer and lower cabinet door | |
| Overhead open shelving | 2-tier fixed open shelves at partition height | |
| CPU bay access | Open under-desk compartment with cable port | |
| Modular connection | Aluminum framing slots connect to adjacent matching cubicle units | |
| Leveling adjustment | 10mm height adjustment on base foot pads | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Open plan office layouts | Creates semi-private individual work zones in high-density office spaces | |
|---|---|---|
| Corporate administrative departments | Suitable for clerical, finance and HR staff requiring document storage | |
| Call center and shared office spaces | Balances visual privacy and team accessibility for daily operations | |
| Small business office fit-outs | Modular design supports scalable layout as headcount increases | |
| Government and institutional offices | Durable construction meets high-traffic public sector use requirements |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables dimensional, safety and strength requirements for commercial use | |
|---|---|---|
| EN 1335-1:2020 | Office furniture seating clearance compatibility for seated work positions | |
| EN 717-1:2004 | Wood-based panel formaldehyde emission test method for indoor air quality |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products load, durability and stability performance standard for office use | |
|---|---|---|
| ANSI/BIFMA X5.6-2022 | Panel systems modular cubicle structural and safety performance standard | |
| ANSI/BIFMA M7.1-2020 | Standard test method for VOC emissions from office furniture systems |
Standards applicable to China-market projects
| GB 18580-2017 | Formaldehyde emission limit ≤0.124mg/m³ for wood-based panels used in indoor furniture | |
|---|---|---|
| GB/T 3324-2017 | General technical requirements for wooden furniture dimensions, strength and stability | |
| GB/T 10357.1-2013 | Desk surface static load and impact durability test standard for office furniture |
This product must meet the following technical requirements: 1. GB 18580-2017: Formaldehyde emission limit ≤0.124mg/m³ for wood-based panels used in indoor furniture; 2. GB/T 3324-2017: General technical requirements for wooden furniture dimensions, strength and stability; 3. GB/T 10357.1-2013: Desk surface static load and impact durability test standard for office furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
