| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall footprint | 2840 x 2840 x 1100 mm | |
|---|---|---|
| Per-station L-shaped worksurface | 1400 x 700 mm | |
| Worksurface height from floor | 750 mm | |
| Seated knee clearance height under desk | 650 mm | |
| Knee recess depth at curved front | 450 mm | |
| Partition thickness | 40 mm | |
| Partition frame wall thickness | 1.2 mm | |
| Mobile pedestal dimensions | 400 x 500 x 600 mm | |
| Cable grommet diameter | 60 mm | |
| Edge banding thickness | 2 mm | |
| Worksurface board thickness | 25 mm | |
| Side modesty panel height | 600 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total set net weight (reference) | 250 kg | |
|---|---|---|
| Per worksurface static load capacity | 80 kg | |
| Recommended user capacity | 4 seated staff | |
| Mobile pedestal caster rolling load rating | 50 kg per unit | |
| Panel surface abrasion resistance | 2000 cycles | |
| Product warranty period | 3 years | |
| Available finish options | 6 standard colors | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Worksurface core | 25mm thick E1 grade particle board | |
|---|---|---|
| Worksurface finish | 0.6mm scratch-resistant melamine laminate | |
| Partition frame | 1.2mm thick anodized aluminum profile | |
| Lower partition panel | Fabric-upholstered 16mm MDF core | |
| Upper partition section | Translucent slatted polycarbonate panel | |
| Mobile pedestal | 0.8mm thick cold-rolled steel drawer box with lock |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable management system | Per-station 60mm grommet + under-desk cable tray | |
|---|---|---|
| Mobile storage pedestal | 3 lockable drawers on 360° swivel casters | |
| Privacy partition design | 1100mm partial height divider | |
| Modular assembly | Knock-down panel and frame connection system |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open plan office staff work areas | Provides separated individual workspaces for teams of 4 in open office layouts | |
|---|---|---|
| Call center and administrative offices | Partitioned layout reduces cross-talk distraction while maintaining supervisor visibility |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable for desk load testing | |
|---|---|---|
| EN 1335-1:2020 | Office furniture work chairs dimensional coordination, used for knee clearance verification | |
| EN 1022:2018 | Furniture seating stability test reference for compatible office chair use |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products safety and performance standard, recommended for worksurface load verification | |
|---|---|---|
| ANSI/BIFMA X5.6-2022 | Panel systems furniture standard, applicable for partition structural integrity testing | |
| ANSI/BIFMA X5.9-2019 | Storage units performance standard, applicable for mobile pedestal load testing |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk panel quality inspection | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limit for wood-based panels, requirement for E1 grade substrate compliance | |
| GB/T 35607-2017 | Green product assessment for furniture, applicable for low-VOC material verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk panel quality inspection; 2. GB 18580-2017: Formaldehyde emission limit for wood-based panels, requirement for E1 grade substrate compliance; 3. GB/T 35607-2017: Green product assessment for furniture, applicable for low-VOC material verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
