Product supplier3-Person L-Shaped Modular Office Cubicle Workstation Set with Mobile Pedestals, E1 grade particleboard with light wood grain melamine laminate
Contact the supplier for production scheduling and quotation.
PRODUCT MODULE 01 / 06
Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 4800 × 1600 × 1200 mm | |
|---|---|---|
| Overall set dimensions (L x D x H) | 4800 x 1600 x 1200 mm | |
| Single L-station footprint | 1600 x 1600 mm | |
| Work surface height from floor | 750 mm | |
| Work surface usable depth at user position | 700 mm | |
| Under-desk knee clearance height | 720 mm | |
| Under-desk knee clearance width at curved edge | 800 mm | |
| Privacy partition screen height | 1200 mm | |
| Partition panel assembly thickness | 30 mm | |
| Work surface panel thickness | 25 mm | |
| Mobile pedestal dimensions (W x D x H) | 400 x 500 x 600 mm | |
| Slatted vent section height on partitions | 200 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
PRODUCT MODULE 02 / 06
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total set net weight reference | 165 kg | |
|---|---|---|
| Per work surface static load capacity | 100 kg | |
| Partition panel impact resistance | 1.5 m drop impact | |
| Work surface scratch resistance rating | 2000 revolutions | |
| Recommended user capacity | 3 persons | |
| Product commercial warranty period | 3 years | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
PRODUCT MODULE 03 / 06
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Work surface panels | E1 grade particleboard with light wood grain melamine laminate | |
|---|---|---|
| Work surface edges | 2mm thick PVC edge banding, waterproof and impact resistant | |
| Partition divider frames | 1.2mm thick powder-coated black steel, corrosion resistant | |
| Solid partition panel sections | 9mm thick melamine board in sage green and light beige | |
| Partition vent sections | Horizontal slatted laminate grille for airflow and partial visibility | |
| Mobile pedestal cabinet bodies | 15mm thick light wood grain melamine composite matching worktops | |
| Pedestal drawer fronts | Sage green melamine panel with integrated key lock | |
| Pedestal casters | 50mm diameter black nylon swivel casters, 2 with brake locks | |
| Connector hardware | Zinc-plated steel interlocking brackets for modular layout reconfiguration | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
PRODUCT MODULE 04 / 06
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable management | Pre-drilled 60mm diameter cable grommet at each work surface corner | |
|---|---|---|
| Mobile storage function | 1 lockable drawer + 1 enclosed storage compartment per rolling pedestal | |
| Privacy partition function | 1200mm high dividers block seated line of sight between adjacent users | |
| Modular reconfiguration | Interlocking bracket system supports L-shape, linear or alternate cluster layouts | |
| Ergonomic work edge | Concave curved front edge at user position supports natural forearm posture | |
| Pedestal mobility | Four swivel casters allow pedestal repositioning under desk or adjacent storage | |
| Partition ventilation | Top slatted grille section allows air circulation between workstations | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
PRODUCT MODULE 05 / 06
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
PRODUCT MODULE 06 / 06
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open plan office areas | Dedicated individual workstations for 3 staff with visual privacy between seats | |
|---|---|---|
| Call center operations | Partitioned stations reduce audio and visual distraction for phone-based work | |
| Small business team spaces | Compact linear layout fits along office walls without wasted floor space | |
| Co-working dedicated desks | Fixed assigned workstations with personal lockable storage for members | |
| Government/admin work areas | Durable commercial construction meets high-traffic office use requirements |
STANDARD S1
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 527-2:2002+A1:2019 | Safety requirements for office work tables and desks, structural stability standards | |
|---|---|---|
| EN 1335-2:2018 | Reference for office furniture ergonomic clearance dimensions for seated use | |
| EN 1022:2019 | Furniture stability test standard for seating and desk storage units |
STANDARD S2
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.9 |
|---|
STANDARD S3
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to worktop and cabinet panels | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, E1 grade required for indoor office use | |
| GB/T 35607-2017 | Performance requirements for office furniture work surfaces |
Standardized tender description text
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to worktop and cabinet panels; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, E1 grade required for indoor office use; 3. GB/T 35607-2017: Performance requirements for office furniture work surfaces; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
