Automatic mm / inch conversion · Core engineering specifications
| Overall footprint | 2800 x 1400 x 1200 mm | |
|---|---|---|
| Work surface height from floor | 760 mm | |
| Single workstation surface size | 1400 x 700 mm | |
| Work surface panel thickness | 25 mm | |
| Partition thickness | 60 mm | |
| Upper glass divider height above desk | 450 mm | |
| Under-desk knee clearance height | 650 mm | |
| Under-desk knee clearance depth | 600 mm | |
| Fixed storage pedestal size per seat | 400 x 600 x 650 mm | |
| PVC edge banding thickness | 2 mm | |
| Support post diameter | 50 mm | |
| Drawer internal usable height | 120 mm | |
| Lower cabinet internal usable height | 480 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall |
Net weight / load capacity / users / durability
| Work surface static load capacity | 300 kg | |
|---|---|---|
| Drawer slide cycle durability | 50000 cycles | |
| Product net weight | 120 kg | |
| Seating capacity | 2 users | |
| Surface abrasion resistance | 2000 cycles | |
| Structural warranty period | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface panels | 25mm E1-grade melamine-faced particleboard with 2mm PVC edge banding | |
|---|---|---|
| Lower partition panels | 18mm melamine-faced particleboard in dark taupe finish | |
| Upper privacy dividers | 5mm clear tempered glass with polished edges | |
| Partition frame and posts | 1.2mm thick powder-coated silver aluminum alloy extrusion | |
| Storage pedestal carcases | 18mm melamine-faced particleboard with matching PVC edge banding | |
| Drawer and door fronts | 18mm light oak-look melamine-faced particleboard with silver metal handles | |
| Desk support brackets | 2mm thick chrome-plated steel brackets connecting desktop to pedestals | |
| Leveling feet | 10mm diameter nylon adjustable feet with threaded steel stems | |
| Drawer lock core | Zinc alloy keyed lock with two keys per pedestal | |
| Door hinges | Concealed cold-rolled steel self-closing cabinet hinges | |
| Cable management grommets | 60mm diameter ABS plastic desk grommets with removable covers | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up |
Adjustment / rotation / tilt / mobility / storage features
| Seated privacy separation | 450mm tall glass upper dividers block direct line of sight between opposite users | |
|---|---|---|
| Drawer security storage | Keyed lock on top pedestal drawer secures personal office supplies and valuables | |
| Under-desk cable routing | Integrated under-desk plastic cable raceway routes power and data cords away from leg space | |
| Floor leveling adjustment | Adjustable nylon feet at partition and pedestal bases compensate for uneven office flooring | |
| Storage organization per seat | One shallow top drawer for small supplies and one lower door cabinet for larger items | |
| Modular connection compatibility | Aluminum frame connection slots allow expansion to additional connected workstation units | |
| Modesty panel coverage | Solid lower partition panels block leg visibility between adjacent and opposite work positions | |
| Edge impact protection | 2mm thick PVC edge banding on all panel edges resists chipping from daily contact and impacts | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Open plan office staff work areas | Modular cross layout efficiently uses floor space for two permanent seated staff positions | |
|---|---|---|
| Small business shared office spaces | Integrated storage and dividers eliminate need for separate cubicle and cabinet purchases | |
| Call center and administrative departments | Low glass dividers provide privacy while allowing supervisor visibility across the floor | |
| Startup office flexible seating zones | Modular frame allows future reconfiguration to add adjacent workstations as teams grow | |
| Temporary project team workspaces | Rapid knock-down assembly supports fast deployment for short-term project teams |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables: safety and strength requirements, applicable to structural performance | |
|---|---|---|
| EN 527-2:2016 | Office work tables: dimensional requirements for seated work desks | |
| EN 12521:2015 | Furniture: strength, durability and safety for non-domestic seating-adjacent tables |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products: safety and performance standard for commercial office work surfaces | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units: performance standard for integrated pedestal drawers and cabinets |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to panel desk structure and finish | |
|---|---|---|
| GB/T 3327-2019 | Office furniture: desks and tables, applicable to work surface dimensions and stability requirements | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to E1-grade MFC panel materials | |
| GB/T 10357.1-2013 | Furniture mechanical performance test for tables, applicable to desktop static load and stability testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to panel desk structure and finish; 2. GB/T 3327-2019: Office furniture: desks and tables, applicable to work surface dimensions and stability requirements; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to E1-grade MFC panel materials; 4. GB/T 10357.1-2013: Furniture mechanical performance test for tables, applicable to desktop static load and stability testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
