Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall assembled dimensions | 2800 x 2800 x 1200 mm | |
|---|---|---|
| Work surface height | 750 mm | |
| Per-segment worktop width | 1400 mm | |
| Worktop depth per segment | 600 mm | |
| Curved internal corner radius | 300 mm | |
| Under-desk knee clearance height | 650 mm | |
| Privacy partition height | 1100 mm | |
| Partition panel thickness | 45 mm | |
| Mobile 3-drawer pedestal dimensions | 400 x 500 x 600 mm | |
| Fixed side cabinet dimensions | 800 x 450 x 650 mm | |
| Tall end storage unit dimensions | 400 x 600 x 1100 mm | |
| Keyboard tray extension travel | 300 mm | |
| Desktop grommet diameter | 60 mm | |
| Mobile pedestal caster diameter | 50 mm | |
| Adjustable leg leveler adjustment range | 15 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Per-workstation desktop static load capacity | 91 kg | |
|---|---|---|
| Total product net weight | 220 kg | |
| Seating capacity | 2 users | |
| Drawer slide cycle rating | 50000 cycles | |
| Caster rolling durability | 20000 cycles | |
| Laminate surface abrasion resistance | 2000 cycles | |
| Manufacturer limited warranty period | 5 years | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Worktop surface | 25mm thick E1-grade melamine-faced chipboard with 2mm ABS edge banding | |
|---|---|---|
| Storage cabinet panels | 18mm thick melamine-faced MDF with PVC edge sealing | |
| Structural support frame | 1.2mm thick powder-coated square steel tubing | |
| Lower privacy divider panels | Fabric-upholstered 12mm hardboard core with tackable surface | |
| Upper divider slat section | 3mm thick frosted translucent acrylic slats with aluminum trim | |
| Drawer hardware | Full-extension cold-rolled steel ball-bearing slides with keyed cam locks |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Modular partition connection | Aluminum extrusion connector system supporting cluster expansion | |
|---|---|---|
| Cable management system | Desktop grommets with under-desk horizontal cable channels | |
| Keyboard platform operation | Pull-out sliding tray with smooth glide, stores flush under worktop | |
| Mobile pedestal mobility | Four dual-wheel swivel casters, lockable drawer for letter/A4 file storage |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open-plan corporate office zones | Suitable for general administrative staff work areas providing defined personal workspaces | |
|---|---|---|
| Small team cluster layouts | Supports 2 adjacent staff positions with integrated storage for efficient space use |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable to work surface performance | |
|---|---|---|
| EN 14073-2:2004 | Office storage furniture safety requirements, applicable to cabinet and pedestal components | |
| EN 1335-2:2009 | Office chair stability reference for seated knee clearance dimensioning |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for load, durability and stability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard for cabinet, pedestal and shelf performance validation |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable to cabinet and worktop components | |
|---|---|---|
| GB/T 3327-2017 | Performance test methods for office desks and workstations, applicable to structural load validation | |
| GB 18584-2001 | Indoor decoration material limit of formaldehyde emission for wood furniture, applicable to substrate safety |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable to cabinet and worktop components; 2. GB/T 3327-2017: Performance test methods for office desks and workstations, applicable to structural load validation; 3. GB 18584-2001: Indoor decoration material limit of formaldehyde emission for wood furniture, applicable to substrate safety; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
