120 Degree Three-Person Panel Workstation with Walnut Worksurfaces and Privacy Screens (model WS-120-3P-WAL-GRY) is listed under L-Shaped Office Desk. Dimensions: 2400 × 2100 × 1200 mm. Materials: 25 mm melamine-faced wood-composite board with walnut wood-grain finish and sealed edge banding. Load capacity: 60 kg per seated position. Product Features: three-seat,cluster,120,degree,layout,corner,workstation,privacy,screen,integrated,storage,walnut,finish,grey,frame. This page consolidates 6 groups of specifications and GB / EN / ANSI/BIFMA standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Brand | GENUOWA | Model | WS-120-3P-WAL-GRY |
| Finished Top Thickness | 50 mm | Effective Knee Clearance | 680 mm high and 900 mm wide per main seat |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
| Product net weight | 165 kg | Distributed worktop load capacity | 60 kg per seated position |
| Privacy screen impact resistance | 10 kg lateral point load at 1100 mm height | Recommended users | 3 persons |
| Recommended chair seat-height range | 520 mm | Durability target for drawer slides | 40000 open-close cycles |
| Surface durability target | Class 2A horizontal laminate wear rating | Edge impact acceptance target | 2 kg dropped from 120 mm at 23 degrees Celsius |
| Top Static Load Reference | 150 kg uniformly distributed | Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
| Worksurface | 25 mm melamine-faced wood-composite board with walnut wood-grain finish and sealed edge banding | Edge protection | 2 mm PVC or ABS impact-resistant edge banding around exposed worktop edges |
| Upper privacy screens | Grey horizontal-slatted infill panels enclosed in a black aluminium or steel perimeter frame | Lower divider panels | Grey fabric-covered or laminate-faced composite panels for desk-height privacy |
| Under-desk modesty panel | Black recessed horizontal modesty apron with grey lower support rail | Support structure | Powder-coated steel rails and vertical support plates with grey floor-standing side panels |
| Seated work arrangement | Three users work independently around a shared 120 degree core, reducing face-to-face exposure while preserving compact clustering | Privacy and spatial division | A 450 mm screen above the desktop plus solid lower panels blocks direct sight lines between neighboring seated positions |
| Integrated personal storage | One under-desk pedestal provides two drawer or door compartments at the left-hand position for stationery and personal items | Cable and equipment planning | Rear cable routing should use a 80 mm grommet or removable panel at each seat, with a horizontal under-top tray capacity of 30 mm bundle diameter |
| Largest carton dimensions | 1250 x 820 x 110 mm | Reference Package Count | 1 set / 2 cartons |
| Reference Assembly Time | 40 minutes per set | Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | Reference Packaging Volume | 1 m³/set |
| Open-plan office and call center | Suitable for dense three-person task clusters where 120 degree screens provide individual visual separation without a full-height partition | Administrative or shared service workspace | Suited to data-entry, booking, administration and hot-desk neighborhoods requiring laptop work, personal drawer storage and orderly cable management |
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Finished Top Thickness | 50 mm | |
|---|---|---|
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Product net weight | 165 kg | |
|---|---|---|
| Distributed worktop load capacity | 60 kg per seated position | |
| Privacy screen impact resistance | 10 kg lateral point load at 1100 mm height | |
| Recommended users | 3 persons | |
| Recommended chair seat-height range | 520 mm | |
| Durability target for drawer slides | 40000 open-close cycles | |
| Surface durability target | Class 2A horizontal laminate wear rating | |
| Edge impact acceptance target | 2 kg dropped from 120 mm at 23 degrees Celsius | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Worksurface | 25 mm melamine-faced wood-composite board with walnut wood-grain finish and sealed edge banding | |
|---|---|---|
| Edge protection | 2 mm PVC or ABS impact-resistant edge banding around exposed worktop edges | |
| Upper privacy screens | Grey horizontal-slatted infill panels enclosed in a black aluminium or steel perimeter frame | |
| Lower divider panels | Grey fabric-covered or laminate-faced composite panels for desk-height privacy | |
| Under-desk modesty panel | Black recessed horizontal modesty apron with grey lower support rail | |
| Support structure | Powder-coated steel rails and vertical support plates with grey floor-standing side panels |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Seated work arrangement | Three users work independently around a shared 120 degree core, reducing face-to-face exposure while preserving compact clustering | |
|---|---|---|
| Privacy and spatial division | A 450 mm screen above the desktop plus solid lower panels blocks direct sight lines between neighboring seated positions | |
| Integrated personal storage | One under-desk pedestal provides two drawer or door compartments at the left-hand position for stationery and personal items | |
| Cable and equipment planning | Rear cable routing should use a 80 mm grommet or removable panel at each seat, with a horizontal under-top tray capacity of 30 mm bundle diameter |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Largest carton dimensions | 1250 x 820 x 110 mm | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open-plan office and call center | Suitable for dense three-person task clusters where 120 degree screens provide individual visual separation without a full-height partition | |
|---|---|---|
| Administrative or shared service workspace | Suited to data-entry, booking, administration and hot-desk neighborhoods requiring laptop work, personal drawer storage and orderly cable management |
EU Market Access Requirements* EN Standards
| Office furniture strength and durability | EN 16139 test level L2 for non-domestic seating-area furniture strength and durability | |
|---|---|---|
| Worksurface surface performance | EN 14322 requirements for melamine-faced wood-based panels, including surface wear, stain and impact checks | |
| Storage hardware safety | EN 14073requirements for office storage furniture safety | |
| Upholstered panel ignition reference | EN 1021cigarette ignition test if the lower panels use fabric covering |
US and Canada office-furniture standards
| Desk strength and fatigue reference | ANSI/BIFMA X5.5 static load, vertical fatigue and stability tests for desk products | |
|---|---|---|
| Storage pedestal reference | ANSI/BIFMA X5.9 load, drawer operation, stability and locking tests for office storage units | |
| Panel screen lateral-load reference | ANSI/BIFMA X5.5 horizontal force procedure applied to divider screens up to 1200 mm high |
Standards applicable to China-market projects
| Formaldehyde emission recommendation | GB/T 39600 E1 limit for artificial boards used in the worksurface and panel substrates | |
|---|---|---|
| Wood furniture dimensional tolerance | GB/T 3324 requirements for wooden furniture dimensions, workmanship and surface quality | |
| Desktop fire safety recommendation | GB 8624 B1 flammability rating for panel and fabric infill materials in commercial office fit-outs |
This product must meet the following technical requirements: 1. Formaldehyde emission recommendation: GB/T 39600 E1 limit for artificial boards used in the worksurface and panel substrates; 2. Wood furniture dimensional tolerance: GB/T 3324 requirements for wooden furniture dimensions, workmanship and surface quality; 3. Desktop fire safety recommendation: GB 8624 B1 flammability rating for panel and fabric infill materials in commercial office fit-outs; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
