| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall workstation dimensions | 3600 x 3600 x 1200 mm | |
|---|---|---|
| Work surface height | 750 mm | |
| Per-seat main L-arm worktop length | 1500 mm | |
| Per-seat return worktop depth | 600 mm | |
| Privacy partition panel thickness | 60 mm | |
| Individual work surface thickness | 25 mm | |
| Mobile pedestal dimensions | 600 x 400 x 600 mm | |
| Seated knee clearance height under worktop | 650 mm | |
| Knee well width per seat | 800 mm | |
| Cable grommet diameter per work surface | 60 mm | |
| Caster diameter for mobile pedestals | 50 mm | |
| Louvered vented partition top section height | 200 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Per work surface static load capacity | 300 kg | |
|---|---|---|
| Total unit gross weight (3-seat set) | 250 kg | |
| Recommended user weight limit per seat | 136 kg | |
| Work surface abrasion resistance cycles | 2000 cycles | |
| Drawer slide operational cycle rating | 50000 cycles | |
| Partition acoustic noise reduction coefficient | 0.45 | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface substrate | 25mm thick E1-grade MFC engineered wood | |
|---|---|---|
| Work surface finish | Light wood grain melamine laminate with PVC edge banding | |
| Privacy divider panel facing | Sage green office-grade woven fabric | |
| Divider structural frame | Powder-coated aluminum extrusion frame | |
| Vented divider top section | ABS plastic louvered slat panels | |
| Mobile pedestal carcass | 18mm thick melamine laminated particle board | |
| Pedestal drawer front | Sage green melamine panel with integrated key lock | |
| Drawer slides | Full-extension cold-rolled steel ball-bearing slides | |
| Pedestal casters | Lockable swivel nylon casters with rubber tread | |
| Connection hardware | Zinc-plated steel modular connecting brackets | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Work surface cable management | 60mm diameter desk grommet at each work position routes power/data cables | |
|---|---|---|
| Mobile pedestal mobility | 4 lockable swivel casters allow pedestal repositioning under desk or adjacent storage | |
| Pedestal drawer storage | 1 lockable utility drawer plus lower open storage compartment per seat secures personal office items | |
| Modular layout reconfiguration | Steel connector brackets allow adding/removing stations to change cubicle layout | |
| Privacy partition screening | 1200mm tall panels block direct line of sight between adjacent seated users | |
| Vented partition airflow | Top louvered slats allow air circulation across workstations without reducing privacy | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Open plan office staff work areas | 3 individual private workspaces suit teams of 3 in general open office layouts | |
|---|---|---|
| Call center and customer service floors | Medium height dividers reduce cross-talk while allowing supervisor visibility | |
| Small startup team work zones | Pre-configured 3-seat layout offers quick deployment for small teams without custom buildout | |
| Administrative and back office departments | Integrated mobile pedestals provide immediate personal storage at each seat |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements for commercial work surfaces | |
|---|---|---|
| EN 1335-1:2020 | Office furniture ergonomic dimensional guidance for desk workstations | |
| EN 71-3:2019 | Migration of certain elements safety requirement for all furniture contact surfaces |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products safety and performance standard for commercial office desks | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units performance standard for mobile pedestals and drawer systems |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable to worktop and pedestal construction | |
|---|---|---|
| GB/T 35607-2017 | Green product assessment standard for furniture, applicable to low-VOC material selection | |
| GB/T 10357.1-2013 | Furniture mechanical performance test standard for desk strength and stability |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable to worktop and pedestal construction; 2. GB/T 35607-2017: Green product assessment standard for furniture, applicable to low-VOC material selection; 3. GB/T 10357.1-2013: Furniture mechanical performance test standard for desk strength and stability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
