Automatic mm / inch conversion · Core engineering specifications
| Overall assembled dimensions | 2400 x 2400 x 1100 mm | |
|---|---|---|
| Single worktop dimensions | 1200 x 600 x 750 mm | |
| Seated knee clearance height under worktop | 600 mm | |
| Knee clearance depth under worktop | 450 mm | |
| Partial privacy partition total height | 1100 mm | |
| Desktop thickness | 38 mm | |
| Partition panel thickness | 32 mm | |
| Mobile pedestal dimensions | 400 x 500 x 600 mm | |
| Partition metal frame profile width | 30 mm | |
| Cable grommet diameter | 60 mm | |
| Adjustable foot height range | 15 mm | |
| Worktop edge overhang | 20 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Total workstation static load capacity | 260 kg | |
|---|---|---|
| Worktop surface scratch resistance | 2000 cycles | |
| Worktop water and stain resistance rating | Level 2 | |
| Workstation net weight (excluding pedestals) | 115 kg | |
| Included mobile pedestal gross weight per unit | 35 kg | |
| Maximum recommended user weight per seat | 120 kg | |
| Hardware cycle life for drawer slides | 50000 open/close cycles | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worksurface core and finish | E1-grade MFC particleboard with light oak melamine laminate | |
|---|---|---|
| Worktop edge treatment | 2mm thick PVC edge banding sealed on all sides | |
| Partition frame construction | Powder-coated gray steel rectangular tubing | |
| Partition infill panels | Double-sided fabric-wrapped MDF core panels with white accent strips | |
| Mobile pedestal body construction | 0.8mm thick cold-rolled steel with white powder-coated finish | |
| Drawer caster wheels | 50mm diameter hard nylon swivel casters (2 locking per pedestal) | |
| Leveling feet components | Nylon base with steel threaded adjustment stem | |
| Cable management grommets | ABS plastic flip-top grommets with black finish | |
| Fastener hardware | Zinc-plated steel screws and connection brackets | |
| Lock system for pedestals | Central keyed cam lock securing all drawers per unit | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Dual independent work zones | Two separated work surfaces with partial dividers for side-by-side staff use | |
|---|---|---|
| Mobile under-desk storage | Two rolling 3-drawer pedestals that slide fully under each work surface | |
| Integrated cable management | Flip-top grommets on each worktop for routing monitor and power cables | |
| Floor level adjustment | Threaded adjustable feet at all frame base points | |
| Modular reconfiguration capability | Bolt-together frame connections allow expansion to larger cubicle clusters | |
| Partial seated privacy | 1100mm tall partitions block direct line of sight between seated users | |
| Pedestal mobility lock | Two locking casters per pedestal hold the cabinet in fixed position | |
| Sound dampening partition surface | Fabric-wrapped infill panels reduce reflected office noise between seats | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Open plan office staff work areas | Two-seat cross layout for dense, space-efficient team seating | |
|---|---|---|
| Small business startup offices | Compact footprint fits two workers without dedicated private offices | |
| Call center and shared workspace | Partial dividers reduce distraction between adjacent workers | |
| Temporary office expansion projects | Knock-down design allows quick assembly and reconfiguration | |
| Administrative department work zones | Included lockable mobile pedestals provide personal document storage | |
| Satellite office locations | Flat packed shipping reduces freight cost for remote office setups |
EU Market Access Requirements* EN Standards
| Office furniture work surface strength requirement | EN 527:2002+A1:2019 | |
|---|---|---|
| Office furniture stability standard | EN 14073:2004 | |
| Office furniture fire performance | EN 1021:2014 |
US and Canada office-furniture standards
| Office desk performance standard | ANSI/BIFMA X2021 | |
|---|---|---|
| Mobile storage pedestal standard | ANSI/BIFMA X2019 |
Standards applicable to China-market projects
| Office furniture desk structural requirement | GB/T 3324 | |
|---|---|---|
| Wood-based panel formaldehyde emission limit | GB 18580 | |
| Office furniture stability requirement | GB/T 10357.7 |
This product must meet the following technical requirements: 1. Office furniture desk structural requirement: GB/T 3324; 2. Wood-based panel formaldehyde emission limit: GB 18580; 3. Office furniture stability requirement: GB/T 10357.7; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
