Automatic mm / inch conversion · Core engineering specifications
| Overall footprint dimensions | 1500 x 1500 x 1100 mm | |
|---|---|---|
| Work surface height above floor | 760 mm | |
| Work surface thickness | 25 mm | |
| Semi-privacy partition height above work surface | 340 mm | |
| Knee clearance width under desk corner | 800 mm | |
| Knee clearance height under work surface | 680 mm | |
| Work surface depth (primary arm) | 600 mm | |
| Mobile storage cabinet dimensions | 800 x 450 x 650 mm | |
| Cable grommet diameter | 60 mm | |
| Partition frame profile thickness | 20 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Work surface static load capacity | 110 kg | |
|---|---|---|
| Mobile storage cabinet total static load | 50 kg | |
| Product net weight | 45 kg | |
| Work surface abrasion resistance | 2000 cycles | |
| Warranty period | 3 years | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface panel | 25mm thick E1 grade particleboard with thermally fused light oak melamine finish | |
|---|---|---|
| Desk side modesty panel | 18mm thick dark grey melamine laminated particleboard | |
| Partition upper section | Ribbed light grey fabric-effect acrylic/laminate slat panel | |
| Partition lower section | 18mm thick dark grey melamine laminated particleboard | |
| Partition support frame | 20mm thick bronze-finish aluminum alloy extrusion | |
| Storage cabinet door/drawer fronts | 16mm thick light oak melamine particleboard with white ABS edge banding | |
| Storage cabinet carcass | 16mm thick dark grey melamine laminated particleboard | |
| Storage cabinet casters | 50mm diameter black nylon swivel casters, 2 with brake locks | |
| Hardware components | Zinc-plated steel cam locks, drawer handles, and connecting screws | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Cable management system | Two 60mm diameter desk-top grommets for routing power and data cables | |
|---|---|---|
| Semi-privacy partition function | Two-sided 340mm high dividers block direct line of sight between adjacent workstations | |
| Mobile storage mobility | Four swivel casters allow the side cabinet to be repositioned or pulled out for access | |
| Lockable drawer storage | Integrated lockable lower drawer secures personal items and confidential documents | |
| Mixed storage configuration | Open middle shelf for frequently accessed items, enclosed side cabinet for concealed storage | |
| Modesty panel coverage | Fixed full-height left side modesty panel blocks leg visibility from adjacent walkways | |
| Assembly structure | Knocked-down flat-pack construction with cam-lock fasteners for on-site assembly | |
| Leveling adjustment | Main desk frame includes small adjustable feet to compensate for uneven floor surfaces | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Open-plan office individual workstations | Semi-privacy partitions reduce visual distraction while maintaining open office accessibility | |
|---|---|---|
| Small business staff work areas | Compact 1.5m footprint fits limited office space without separate storage furniture | |
| Home office dedicated work zones | Integrated storage eliminates need for separate filing cabinets in residential workspaces | |
| Temporary project team seating | Knocked-down design allows fast reconfiguration for short-term project workspace setups | |
| Call center agent work positions | Cable management and partitioned layout support single-user computer-based daily work |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables – Part 1: Dimensions, applicable to work surface height and clearance requirements | |
|---|---|---|
| EN 527-2:2002+A1:2006 | Office work tables – Part 2: Mechanical safety requirements, applicable to structural load testing | |
| EN 13986:2004+A1:2015 | Wood-based panels for structural use, applicable to desk panel material performance |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk Products standard, applicable to work surface load, stability and durability testing |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to panel desk structural stability | |
|---|---|---|
| GB/T 3327-2016 | Performance test methods for office desks, applicable to work surface load and durability testing | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, minimum E1 grade required for indoor use |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to panel desk structural stability; 2. GB/T 3327-2016: Performance test methods for office desks, applicable to work surface load and durability testing; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, minimum E1 grade required for indoor use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
