Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Finished Top Thickness | 50 mm | |
|---|---|---|
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Recommended users | 2 reception staff | |
|---|---|---|
| Distributed worktop load | 80 kg | |
| Equipment bay load | 30 kg | |
| Upper counter display load | 40 kg | |
| Panel and frame lateral stability load | 50 kg horizontal service load | |
| Product net weight | 145 kg | |
| Floor contact points | 8 adjustable glides | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Main worktop | 25 mm melamine-faced wood-based panel with PVC edge banding | |
|---|---|---|
| Storage cabinet panels | 18 mm melamine-faced particleboard in light warm grey | |
| Privacy screen slats | Translucent frosted polycarbonate or acrylic strips in a dark metal frame | |
| Structural screen frame | 25 x 25 mm powder-coated steel or aluminium-look steel rectangular framing | |
| Lower modesty panel | 18 mm melamine-faced grey panel with horizontal trim rails | |
| Side barrier panels | Light-grey melamine panels separated by dark aluminium-look mullions | |
| Right equipment bay interior | Dark grey melamine-lined compartment with horizontal cable access hole | |
| Floor adjustment hardware | 30 mm diameter nylon or PP adjustable glides with steel threaded stems | |
| Fasteners and connectors | Cam-lock connectors, corner brackets and black screw-cap covers | |
| Edge protection | PVC or ABS edge banding on exposed worktop and cabinet edges | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Workstation layout | L-shaped arrangement combines a long two-position reception desk with a right-side return and storage tower | |
|---|---|---|
| Privacy and visitor screening | Framed translucent slat screen limits direct visibility while preserving light transfer across the front and left side | |
| Cable routing on worktop | 320 x 80 mm oval grommet allows monitor, keyboard and power cables to pass below the rear work surface | |
| Vertical equipment cable management | Circular lower grommet in the right equipment bay routes cables from the CPU area toward floor power outlets | |
| Computer equipment storage | Open lower right bay accommodates a tower PC, printer CPU, or bag storage with front access | |
| Raised visitor transaction area | Right counter provides a standing-height surface for documents, visitor sign-in and exchange | |
| Levelling on uneven floors | Eight threaded glides allow independent height adjustment at cabinet and frame feet | |
| Modular panel assembly | Bolted screen frames and cabinet modules can be shipped flat and assembled on site with cam and screw connectors | |
| Seated staff orientation | Staff face the visitor screen while the open knee bay supports chair placement under the long worktop | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Total packed gross weight | 165 kg | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Corporate lobby | Suitable for a company entrance where two receptionists manage visitors, deliveries and access control | |
|---|---|---|
| Hotel or serviced-office front desk | Fits check-in, key handover and document exchange through the raised right-hand counter | |
| Medical or education reception | Provides staff-side privacy and a separated visitor barrier while maintaining visual contact through slats | |
| Open-plan administration area | Works as a dedicated welcome point separating waiting visitors from back-office work zones | |
| Small branch office or showroom | Combines greeting counter, workstation and computer equipment storage in one compact L-shaped footprint | |
| Reception with cable-heavy equipment | Suitable for monitors, card terminals, phones and PCs using the desktop grommet and lower cable hole |
EU Market Access Requirements* EN Standards
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.5 Desk and Table Products |
|---|
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
