Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 2800 x 1200 x 1200 mm | |
|---|---|---|
| individual workstation worksurface size | 1200 x 600 mm | |
| worksurface thickness | 25 mm | |
| worksurface height from floor | 750 mm | |
| privacy divider total height | 1200 mm | |
| knee clearance height under worksurface | 620 mm | |
| knee clearance depth per seat | 450 mm | |
| edge banding thickness | 2 mm | |
| mobile pedestal dimensions | 400 x 500 x 600 mm | |
| steel frame tube wall thickness | 1.8 mm | |
| cable grommet diameter | 60 mm | |
| modesty panel height | 400 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| work surface static load capacity | 120 kg | |
|---|---|---|
| drawer slide cycle rating | 50000 cycles | |
| net weight per complete workstation set | 180 kg | |
| recommended user capacity | 4 people | |
| surface abrasion resistance | 2000 cycles | |
| manufacturer warranty period | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| worksurface core | E1 grade melamine-faced particleboard | |
|---|---|---|
| support frame | White powder-coated square steel tubing | |
| privacy divider upper panel | Clear acrylic sheet within steel frame | |
| privacy divider lower panel | Melamine-faced panel matching worktop finish | |
| modesty panels | White melamine-faced engineered board | |
| mobile pedestal cabinet | Dual-tone melamine-faced engineered board | |
| mobile pedestal casters | Black nylon swivel casters, 2 with brake | |
| edge banding | 2mm thick impact-resistant PVC edging | |
| pedestal drawer lock | Zinc alloy keyed cam lock | |
| hardware fasteners | Zinc-plated steel screws and connecting fittings | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| modular linear layout | Connectable segments support 4 individual seated work positions in a single row | |
|---|---|---|
| seated privacy screening | 1200mm tall dividers block direct line of sight between adjacent seated users | |
| mobile under-desk storage | Each seat has a dedicated 2-drawer wheeled pedestal that slides fully under the work surface | |
| cable management grommets | 60mm diameter pass-through ports at each work position route power and data cables under the desk | |
| pedestal mobility | Four swivel casters per pedestal allow repositioning without lifting; two casters lock to hold position | |
| lockable drawer storage | Keyed lock on each pedestal secures personal documents and office supplies | |
| knock-down assembly | Frame and panels disassemble for flat-pack shipping and on-site installation | |
| scratch-resistant work surface | Melamine laminate finish resists water, stains, and daily abrasion from office equipment | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| open plan office staff areas | Provides dedicated divided workspaces for teams in open floor plans without full cubicle walls | |
|---|---|---|
| call center and administrative offices | Compact 600mm seat depth fits high-density seat layouts for daily task work | |
| co-working flexible office spaces | Modular structure supports reconfiguration and dedicated assigned seats for members | |
| startup and small business offices | Light wood and white finish fits modern minimalist office interiors for 4-person teams | |
| training and temporary project spaces | Durable construction supports frequent use and repositioning of storage units |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable to worksurface and frame structural design | |
|---|---|---|
| EN 527-2:2016 | Office worktables dimensional and ergonomic requirements, applicable to seated clearance dimensions | |
| EN 13722:2004 | Office furniture mobile storage pedestals performance requirements, applicable to drawer durability |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Standard for desk products, applicable to static load, stability and durability testing of work surfaces | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Standard for mobile storage units, applicable to pedestal drawer cycle and load testing |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable to worksurface and panel components | |
|---|---|---|
| GB/T 3327-2016 | Performance requirements for office desks and workstations, applicable to static load and stability testing | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to all engineered wood components | |
| GB/T 10357.1-2013 | Furniture mechanical performance test for tables, applicable to structural load verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable to worksurface and panel components; 2. GB/T 3327-2016: Performance requirements for office desks and workstations, applicable to static load and stability testing; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to all engineered wood components; 4. GB/T 10357.1-2013: Furniture mechanical performance test for tables, applicable to structural load verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
