Automatic mm / inch conversion · Core engineering specifications
| Overall footprint | 1600 x 1400 x 1200 mm | |
|---|---|---|
| Work surface height | 750 mm | |
| Worktop thickness | 25 mm | |
| Knee well clearance width | 700 mm | |
| Knee well clearance height | 650 mm | |
| Lower solid partition height | 900 mm | |
| Upper perforated partition height | 300 mm | |
| Partition panel thickness | 83 mm | |
| Partition frame aluminum profile wall thickness | 1.5 mm | |
| Mobile pedestal dimensions | 420 x 460 x 650 mm | |
| Caster diameter for pedestal | 50 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Static worktop uniform load capacity | 100 kg | |
|---|---|---|
| Total workstation net weight | 85 kg | |
| Recommended user capacity | 1 person | |
| Melamine surface abrasion resistance | 2000 cycles | |
| Product warranty period | 8 years | |
| Available color options | 60 | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop surface | 25 mm E1 grade melamine-faced MFC board with 2 mm PVC edge banding | |
|---|---|---|
| Partition frame structure | 1.5 mm thick extruded aluminum profile with silver anodized finish | |
| Lower partition panels | Tackable beige fabric wrapped over high-density fiberboard core | |
| Upper partition panels | Perforated steel vent panels with matching powder-coated finish | |
| Desk support brackets | 1.2 mm thick cold-rolled steel with powder-coated light gray finish | |
| Mobile pedestal body | 18 mm thick melamine-faced MFC board matching worktop finish | |
| Pedestal lock mechanism | Keyed cam lock with chrome-finished escutcheon | |
| Pedestal casters | Black nylon swivel casters, two with integrated locking brakes | |
| Partition connection hardware | Zinc-plated steel modular joinery connectors | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Cable management access | Dual desk-top cable grommets routed to aluminum under-desk raceway | |
|---|---|---|
| Mobile pedestal mobility | 360° swivel casters with two lockable positions for fixed placement | |
| Pedestal storage configuration | One upper shallow stationery drawer and one lower hanging file drawer | |
| Partition modularity | Tool-connected panel system allowing reconfiguration to multi-seat layouts | |
| Privacy performance | 900 mm high solid lower panels block seated line of sight between adjacent workstations | |
| Assembly configuration | Knock-down flat-pack assembly with all required hardware included | |
| Work surface functionality | Scratch-resistant, water-repellent melamine surface suitable for daily office computer work | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Open-plan office spaces | Individual dedicated workstations separated by privacy dividers to reduce distraction | |
|---|---|---|
| Call center environments | Acoustic and visual separation for staff handling voice calls with computer equipment | |
| Startup and co-working spaces | Modular reconfigurable workstations that can be rearranged as team sizes change | |
| Government and corporate administrative offices | Durable standardized workstations for long-term daily clerical and computer work | |
| Small business back-office areas | Space-efficient L-shaped layout provides extended work surface without excess floor space |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and dimensional requirements, applicable to work surface and clearance | |
|---|---|---|
| EN 1335-1:2020 | Office furniture work chair interaction reference for knee well clearance dimensions | |
| EN 1022:2018 | Furniture stability requirements for seating and storage units, applicable to mobile pedestal |
US and Canada office-furniture standards
| ANSI/BIFMA X5.1-2017 | Office desk safety and performance standard for load and stability testing | |
|---|---|---|
| ANSI/BIFMA X5.6-2016 | Office panel systems performance standard for partition strength and durability | |
| ANSI/BIFMA X5.3-2020 | Vertical filing and storage cabinet standard for mobile pedestal load testing |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable to MFC worktop and pedestal | |
|---|---|---|
| GB/T 3327-2016 | Office desk dimensional and stability requirements, applicable to worktop and support structure | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to all MFC components | |
| GB/T 24821-2009 | Office panel partition system performance requirements, applicable to cubicle dividers |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable to MFC worktop and pedestal; 2. GB/T 3327-2016: Office desk dimensional and stability requirements, applicable to worktop and support structure; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to all MFC components; 4. GB/T 24821-2009: Office panel partition system performance requirements, applicable to cubicle dividers; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
