Automatic mm / inch conversion · Core engineering specifications
| Overall footprint | 2400 x 1200 x 1200 mm | |
|---|---|---|
| Work surface height from floor | 750 mm | |
| Individual work surface size per seat | 1200 x 600 mm | |
| Under-desk knee clearance height | 670 mm | |
| Under-desk knee clearance depth per seat | 480 mm | |
| Lower solid partition panel height | 800 mm | |
| Upper slatted translucent screen height | 400 mm | |
| Work surface thickness | 25 mm | |
| PVC edge banding thickness | 2 mm | |
| Mobile pedestal dimensions | 400 x 500 x 600 mm | |
| Cable grommet diameter | 60 mm | |
| Partition aluminum frame thickness | 2 mm | |
| Pedestal caster diameter | 50 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Per work surface static load capacity | 100 kg | |
|---|---|---|
| Pedestal drawer static load per drawer | 30 kg | |
| Set total net weight | 130 kg | |
| Lower partition sound transmission reduction | 12 dB | |
| Seating capacity | 2 users | |
| Work surface abrasion resistance cycles | 2000 cycles | |
| Caster rolling durability cycles | 20000 cycles | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Work surface core | 18mm particleboard core | |
|---|---|---|
| Work surface finish | Light maple melamine laminate, stain and scratch resistant | |
| Work surface edging | 2mm PVC edge banding, impact resistant | |
| Partition frame | White powder-coated aluminum extrusion framing | |
| Lower partition panel | Fabric-faced MDF core panel, sound absorbing | |
| Upper partition screen | Horizontal slatted translucent acrylic/PP screen | |
| Modesty panel under desk | 16mm grey melamine hardboard | |
| Mobile pedestal body | Light maple melamine particleboard cabinet | |
| Pedestal drawer front | Grey lockable steel drawer front with integrated cam lock | |
| Pedestal casters | Hard nylon dual-wheel swivel casters | |
| Structural support frame | White powder-coated steel box tube underframe | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints |
Adjustment / rotation / tilt / mobility / storage features
| Cable management access | Round cable grommet per work surface near partition for power/data cords | |
|---|---|---|
| Partition privacy separation | Half-height panels block direct line of sight between seated users | |
| Mobile pedestal storage | 2 lockable drawers per seat: 1 utility drawer, 1 filing drawer | |
| Pedestal mobility | Full-swivel casters allow repositioning under desk or to adjacent space | |
| Modular reconfiguration | Aluminum frame connection hardware supports reconfiguring to 4/6-person clusters | |
| Upper screen ventilation | Slatted upper screen allows air flow and partial light transmission while reducing distraction | |
| Pedestal lock security | Cam lock secures both drawers per pedestal to protect personal items and documents | |
| Under-desk modesty coverage | Full-width modesty panel conceals seated user leg area from adjacent walkways | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Open-plan office staff seating | 2-person dedicated workstations for administrative or data entry staff | |
|---|---|---|
| Small business office setup | Compact footprint suitable for startup offices with limited floor space | |
| Temporary project team space | Modular design supports quick rearrangement for short-term project teams | |
| Back-office operational areas | Sufficient privacy and cable access for routine daily computer-based work | |
| Shared workspace environments | Dual separate work surfaces allow shared use without workspace conflict |
EU Market Access Requirements* EN Standards
| Office furniture strength and stability | EN 527:2002, work surface strength and dimensional requirements | |
|---|---|---|
| Office storage pedestal safety | EN 14073:2004, storage furniture strength and stability |
US and Canada office-furniture standards
| Work surface load test | ANSI/BIFMA X2021desk products durability and safety standard | |
|---|---|---|
| Mobile storage unit test | ANSI/BIFMA X2022office storage units performance standard |
Standards applicable to China-market projects
| Desktop panel environmental grade | GB/T 39600ENF grade, formaldehyde emission ≤0.025 mg/m³ | |
|---|---|---|
| Metal frame coating adhesion | GB/T 9286cross-cut test grade 1 | |
| Office desk stability | GB/T 3326static load and stability test requirements |
This product must meet the following technical requirements: 1. Desktop panel environmental grade: GB/T 39600ENF grade, formaldehyde emission ≤0.025 mg/m³; 2. Metal frame coating adhesion: GB/T 9286cross-cut test grade 1; 3. Office desk stability: GB/T 3326static load and stability test requirements; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
