Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall footprint | 2400 x 1200 x 1100 mm | |
|---|---|---|
| Individual work surface | 1200 x 600 mm per user | |
| Finished work surface height | 750 mm | |
| Work surface thickness | 28 mm | |
| Edge banding thickness | 3 mm | |
| Back privacy screen height above floor | 1100 mm | |
| Screen height above desktop | 350 mm | |
| Center divider width per station | 600 mm | |
| Privacy panel thickness | 51 mm | |
| Front modesty panel height | 450 mm | |
| Seated knee opening width | 1100 mm per station | |
| Seated knee clearance depth | 600 mm | |
| Underside knee clearance height | 680 mm | |
| Support post section | 40 x 40 x 1.2 mm square tube | |
| Leveling glide adjustment | 20 mm | |
| Recommended chair footprint per bay | 650 x 650 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Product net weight | 120 kg | |
|---|---|---|
| Distributed static load per work surface | 100 kg | |
| Concentrated desktop load | 40 kg at one point | |
| Supported users | 2 seated users | |
| Panel tacking capacity | Light paper and memo use with pins or hook-and-loop pads | |
| Frame lateral stability rating | 2 percent of system weight applied at panel top | |
| Leveling glide load capacity | 60 kg per glide | |
| Surface vertical deflection under rated load | 3 mm maximum | |
| Adjustment cycles per leveling glide | 1000 cycles | |
| Warranty duration | 5 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Work surface substrate | 18 mm MFC particleboard core under laminate face | |
|---|---|---|
| Work surface finish | High-pressure laminate or melamine laminate in light neutral tone | |
| Edge protection | 3 mm PVC or ABS impact-resistant edge banding | |
| Upper privacy panels | Fabric-faced composite board in light gray | |
| Terracotta accent band | Fabric or laminate-covered panel strip with dark perimeter trim | |
| Lower modesty panels | Light gray composite board with dark horizontal trim rails | |
| Structural support frame | Powder-coated square steel tube, 40 x 40 x 1.2 mm | |
| Vertical panel posts | Dark gray aluminum extrusions or powder-coated steel sections | |
| Panel core option | Foam-padded MDF or compact composite tackable core | |
| Feet and glides | Injection-molded plastic bases with steel threaded stems | |
| Fasteners and brackets | Zinc-plated steel connector plates, cam bolts and corner brackets | |
| Color offer | 2 standard colorways: light gray with terracotta accent or all-gray |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Two independent work bays | Two 1200 mm wide seated stations are separated by a center divider for side-by-side staff use | |
|---|---|---|
| Low privacy screening | 350 mm high back screen above desktop reduces visual distraction without blocking room visibility | |
| Modular panel connection | Posts connect back, center and side panels with brackets to form a straight two-seat run | |
| Floor leveling | Threaded glides provide 20 mm vertical compensation for uneven office floors | |
| Front modesty coverage | 450 mm solid lower panels conceal legs and cable clutter from the aisle | |
| Open chair access | Each station provides an open 1100 x 600 mm knee bay without built-in drawers | |
| Cable management provision | One 60 mm desk grommet per user can be fitted at the rear work surface | |
| Panel expansion | The post system can extend to additional straight bays using matching panel connectors | |
| Storage compatibility | Mobile pedestals up to 400 mm wide fit under each work surface without blocking the knee opening | |
| Power readiness | Horizontal raceway covers can accommodate one 3-socket strip per station when wired on site | |
| Installation method | Knock-down assembly using cam connectors, support posts, screws and leveling feet | |
| Restacking limitation | Panels reconfigure by disassembly and bracket relocation; they are not sliding or folding partitions |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Packaging form | 4 flat-pack cartons plus one hardware carton, palletized for freight | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open-plan office | Creates two defined staff seats in one 2400 mm linear run for dense team layouts | |
|---|---|---|
| Call center | Low screens provide visual separation while preserving supervisor visibility and quick communication | |
| Administration area | Supports laptop, paperwork and phone tasks on two independent 1200 x 600 mm surfaces | |
| Finance or HR shared workstation | Separates adjacent users with a center divider for document privacy during routine work | |
| Project team zone | Can be repeated in straight runs to create standardized bench-style neighborhoods | |
| Temporary staffing layout | Knock-down construction and leveling feet support reconfiguration on standard raised or carpeted floors | |
| Hot-desking neighborhood | Pairs two users without assigned storage, leaving space for mobile pedestals when needed | |
| Educational staff room | Provides compact seated computer workstations for teachers or administrative operators |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Defines safety, strength and dimensional requirements for office desks and work surfaces | |
|---|---|---|
| EN 527-2:2011 | Provides mechanical safety, durability and stability test methods for office desks | |
| EN 1022:2018 | Specifies seating stability, relevant when validating chair-and-workstation interaction | |
| EN 13986:2004+A1:2015 | Covers wood-based panels for construction and furniture performance classification |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Office desk static, vertical, horizontal and durability tests apply to the work surfaces | |
|---|---|---|
| ANSI/BIFMA X5.6-2022 | Panel systems test guidance applies to screens, connections and freestanding system stability | |
| ANSI/BIFMA e3-2019 | Use as optional sustainability, material and chemical reporting framework |
Standards applicable to China-market projects
| GB/T 3324-2017 | Use for general wooden furniture dimensions, workmanship and inspection of wood-based work surfaces | |
|---|---|---|
| GB/T 3325-2017 | Use for metal furniture strength, dimensional and surface-quality checks on steel supports | |
| GB 18580-2017 | Use formaldehyde emission limits for wood-based panel substrates at E1 or lower | |
| GB/T 10357.5-2011 | Use desk strength and load test methods to validate the 100 kg desktop rating | |
| GB/T 10357.7-2013 | Use furniture stability test method to assess tipping and lateral stability |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Use for general wooden furniture dimensions, workmanship and inspection of wood-based work surfaces; 2. GB/T 3325-2017: Use for metal furniture strength, dimensional and surface-quality checks on steel supports; 3. GB 18580-2017: Use formaldehyde emission limits for wood-based panel substrates at E1 or lower; 4. GB/T 10357.5-2011: Use desk strength and load test methods to validate the 100 kg desktop rating; 5. GB/T 10357.7-2013: Use furniture stability test method to assess tipping and lateral stability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
