| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 2800 x 1200 x 1100 mm | |
|---|---|---|
| desktop height | 750 mm | |
| single workstation surface size | 1400 x 600 mm | |
| partition total height | 1100 mm | |
| desktop thickness | 25 mm | |
| knee clearance height under desk | 680 mm | |
| knee clearance width per seat | 600 mm | |
| edge banding thickness | 1 mm | |
| cable grommet diameter | 60 mm | |
| drawer internal depth | 450 mm | |
| CPU shelf internal size | 250 x 500 mm | |
| upper transparent partition panel height | 280 mm | |
| frame metal wall thickness | 1.2 mm | |
| pedestal external size | 400 x 500 x 650 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat |
Net weight / load capacity / users / durability
| desktop static load capacity | 120 kg | |
|---|---|---|
| unit net weight | 120 kg | |
| recommended user capacity | 2 people | |
| surface abrasion resistance | 2000 cycles | |
| drawer slide cycle life | 50000 cycles | |
| product warranty | 10 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| work surface | E1-grade melamine-faced chipboard, light maple woodgrain finish, scratch-resistant coating | |
|---|---|---|
| partition frame | Powder-coated matte white steel, modular T-shaped joinery | |
| upper partition panel | Semi-transparent clear acrylic panel, framed in white steel | |
| middle privacy strip | Opaque matte gray PVC sound-dampening panel | |
| lower partition panel | Light maple melamine board matching work surface finish | |
| drawer pedestal | Light gray melamine cabinet body, white curved plastic pulls, top drawer with key lock | |
| CPU shelf | Light gray melamine shelf base, black nylon swivel casters, steel support brackets | |
| edge banding | 1mm thick PVC edging, color-matched to work surface, impact-resistant | |
| hardware fittings | Zinc-plated steel screws, cam-lock connectors for knock-down assembly | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| partition privacy screening | 1100mm tall T-dividers separate two work positions, reducing visual distraction between adjacent users | |
|---|---|---|
| lockable drawer storage | Top pedestal drawer includes key lock for securing personal/official documents, two lower drawers for general supplies | |
| pull-out rolling CPU storage | Under-desk caster-mounted shelf slides out for easy PC access and maintenance, retracts fully when not in use | |
| desktop cable management | 60mm diameter cable grommet at rear corner of each work surface routes power and data cables off the work area | |
| knock-down modular assembly | Cam-lock connected frame and panels allow reconfiguration into extended workstation clusters or disassembly for relocation | |
| smooth drawer operation | 3-section ball-bearing slides enable full drawer extension with silent soft-close action at travel end | |
| leveling adjustment | Adjustable foot glides at base of frame compensate for uneven office floors to keep work surface stable | |
| surface easy maintenance | Stain-resistant melamine surface wipes clean with standard office cleaning products, no special treatment required | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| number of shipping cartons | 3 | |
|---|---|---|
| shipping carton dimensions | 1450 x 680 x 180 mm, 1150 x 620 x 120 mm, 550 x 420 x 670 mm | |
| shipping gross weight | 120 kg | |
| total shipping volume | 0.45 CBM | |
| assembly time | 50 minutes | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| open plan office space | Provides dedicated divided work zones for 2 staff without full-height wall construction | |
|---|---|---|
| small team startup offices | Compact footprint fits limited office floor area, with integrated storage to reduce additional furniture needs | |
| call center and admin departments | Privacy screens reduce cross-talk distraction, cable management supports headsets and computer equipment | |
| temporary project work areas | Modular KD construction allows fast installation and reconfiguration for short-term project teams | |
| government/enterprise staff work areas | Durable commercial-grade construction meets daily high-traffic office use requirements |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables, safety and strength requirements for commercial desk products | |
|---|---|---|
| EN 527-2:2016 | Office work tables, dimensional and ergonomic requirements for seated work positions | |
| EN 13722:2004 | Office furniture, storage units, requirements for drawer pedestal strength and durability |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products, standard for static load, durability and stability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units, performance requirements for drawer units and pedestals |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk panel structural performance | |
|---|---|---|
| GB/T 3327-2016 | Office desks and tables, applicable to work surface height, stability, and load testing | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, E1 grade requirement for indoor office use | |
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable to substrate material performance requirements |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk panel structural performance; 2. GB/T 3327-2016: Office desks and tables, applicable to work surface height, stability, and load testing; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, E1 grade requirement for indoor office use; 4. GB/T 4897.3-2003: Particleboard for furniture use, applicable to substrate material performance requirements; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
