Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall cluster dimensions | 2050 x 1600 x 1200 mm | |
|---|---|---|
| Work surface height | 750 mm | |
| Work surface thickness | 25 mm | |
| Privacy partition total height | 1200 mm | |
| Privacy partition thickness | 60 mm | |
| Primary work surface width (per station) | 1650 mm | |
| Primary work surface depth (per station) | 600 mm | |
| Knee clearance opening height | 600 mm | |
| Knee clearance opening width | 500 mm | |
| Integrated left pedestal width | 400 mm | |
| Integrated left pedestal depth | 600 mm | |
| Mobile CPU shelf dimensions | 300 x 500 mm | |
| Cable grommet diameter | 60 mm | |
| Modesty panel height | 400 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Desktop static load capacity | 90 kg | |
|---|---|---|
| Partition panel impact resistance | 200 N | |
| Caster rolling load rating (per caster) | 15 kg | |
| Net weight per 2-seat cluster | 163 kg | |
| Recommended user weight limit per station | 136 kg | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Work surface | 25mm melamine-faced particleboard with ABS impact-resistant edging, scratch-resistant finish | |
|---|---|---|
| Privacy partition frame | Anodized aluminum alloy extrusion framing with anti-corrosion coating | |
| Upper partition section | Translucent white slatted panel for light transmission and partial visual separation | |
| Lower partition section | 18mm thick MFC panel with matte green solid finish for seated privacy | |
| Storage cabinet body | 18mm thick white melamine-faced particleboard with matching edge banding | |
| Mobile CPU shelf | 18mm thick particleboard shelf with black nylon swivel casters |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable management | Desktop cable grommet routes power and data cables from surface to under-desk space | |
|---|---|---|
| Lockable storage | Integrated pedestal includes lockable top drawer and lower door cabinet for secured personal storage | |
| Mobile CPU storage | Wheeled pull-out CPU shelf under desk return allows easy access and ventilation for computer towers | |
| Modular connection | Pre-drilled connection points allow linking to identical adjacent workstations for open-plan cluster layouts |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open plan office layouts | Provides seated privacy while supporting collaborative multi-seat staff arrangement | |
|---|---|---|
| Small business administrative work areas | Integrated storage reduces need for additional filing furniture |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Applicable for safety, strength and durability requirements for office work desks | |
|---|---|---|
| EN 1335-1:2020 | Applicable for dimensional coordination with office chair seating | |
| EN 1022:2018 | Applicable for furniture stability requirements for seated workstations |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Applicable performance standard for desk products - strength, durability and stability | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Applicable standard for office storage units integrated into workstations |
Standards applicable to China-market projects
| GB/T 3324-2017 | Applicable for general technical requirements of wooden office furniture | |
|---|---|---|
| GB/T 3327-2023 | Applicable for desk performance, dimensional stability and safety requirements | |
| GB 18584-2001 | Applicable for formaldehyde emission limits for interior wooden furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applicable for general technical requirements of wooden office furniture; 2. GB/T 3327-2023: Applicable for desk performance, dimensional stability and safety requirements; 3. GB 18584-2001: Applicable for formaldehyde emission limits for interior wooden furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
