Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall footprint | 1500 x 1500 x 1200 mm | |
|---|---|---|
| Main work surface | 1400 x 600 x 25 mm | |
| Work surface height | 750 mm | |
| Main knee opening | 600 mm wide x 500 mm deep x 680 mm high | |
| Side storage return | 450 x 1400 x 1200 mm | |
| Open upper hutch compartments | 4 compartments, largest bay 520 x 350 x 350 mm | |
| Open lower storage bays | 2 compartments, each 350 x 450 x 380 mm | |
| Privacy screen | 1200 mm total height, 40 mm panel thickness, 300 mm translucent upper band | |
| Desktop cable grommet | 160 x 60 mm oval opening | |
| Panel support thickness | 25 mm main vertical panels | |
| Leveling glide projection | 15 mm below cabinet base | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Desktop distributed load | 91 kg | |
|---|---|---|
| Open shelf load | 16 kg per shelf | |
| Lockable lower compartment load | 15 kg | |
| Drawer slide durability | 50,000 opening cycles | |
| Suggested occupant load | 1 person | |
| Product net weight | 136 kg | |
| Leveling adjustment | 10 mm vertical compensation per glide | |
| Warranty duration | 6 years | |
| Surface color options | 6 finishes | |
| Reference Static Load | 150 kg depending on category |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Work surface | 25 mm engineered wood panel with walnut-grain melamine face and sealed substrate | |
|---|---|---|
| Case panels | Warm grey melamine-faced engineered wood with matching exposed edges | |
| Edge protection | 2 mm PVC edge banding with subtly rounded front profile | |
| Upper privacy screen | Frosted ribbed translucent panel in a grey metal or hard-plastic frame | |
| Lower privacy fascia | Walnut-grain melamine panel with horizontal grey trim | |
| Storage dividers | 25 mm melamine-faced engineered wood shelves and upright partitions | |
| Lockable front | Walnut-grain melamine door or drawer front with keyed cylinder lock | |
| Drawer slides | Steel three-section ball-bearing slides with quiet running specification | |
| Cable grommet | White plastic oval grommet with removable cover and brush/slot opening | |
| Leveling glides | Black nylon base with threaded steel stem and plated insert | |
| Structural hardware | Cam bolts, dowels, screws, and corner connectors for panel jointing | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Seated work configuration | Single-user L-shaped layout places writing surface at 750 mm with 680 mm knee clearance | |
|---|---|---|
| Privacy screening | Rear 1200 mm divider combines solid lower modesty protection with ribbed translucent upper band | |
| Cable management | Oval desktop grommet routes monitor and power cables from tabletop into enclosed rear cavity | |
| Integrated open storage | Four upper and two lower open bays separate books, binders, and daily documents | |
| Secured storage | One keyed lower wood-grain compartment secures personal items or confidential documents | |
| Floor leveling | Threaded glides under the case and desk allow a 10 mm correction for uneven floors | |
| Modular installation | Storage return, desk panels, rear screen, and shelves assemble around the L corner | |
| Under-desk modesty panel | Solid grey rear panel and side end panel conceal cables and the user's leg area | |
| Expansion potential | Grey-framed screen edge can align with adjacent workstation panels for cluster planning | |
| Lockable drawer/door front | 400 x 500 mm visible front face | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open-plan office | Suitable for individual staff positions where privacy, storage, and monitor cabling must fit one footprint | |
|---|---|---|
| Administrative workstation | Appropriate for clerks, coordinators, and accounting staff using documents, a monitor, and locked personal storage | |
| Call-center or shared service area | L-shaped surface and 1200 mm screen support focused work while retaining visual contact above the desk | |
| Small private office | Combines desk, bookshelves, and filing storage without requiring separate furniture pieces | |
| Training administration room | Provides storage for manuals, forms, and daily equipment beside a seated writing surface | |
| Project team neighborhood | Can be arranged in rows or clusters by joining compatible panel-edge profiles |
EU Market Access Requirements* EN Standards
| Office furniture structural safety | EN 16139:2013+A2:2018, strength and safety for non-domestic seating work furniture contexts | |
|---|---|---|
| Office work surface dimensions | EN 527:2011, dimensions and safety requirements for office desks | |
| Office work surface mechanical tests | EN 527:2014, mechanical safety requirements for office desks |
US and Canada office-furniture standards
| Office desk safety and performance | ANSI/BIFMA X2022safety and performance standard for office desks | |
|---|---|---|
| Storage units and cases | ANSI/BIFMA X2019storage cabinets, shelves, and lockable case performance | |
| Facility panels and screens | ANSI/BIFMA X2023panel systems and modular workspace components |
Standards applicable to China-market projects
| Formaldehyde emission | GB 18580interior decoration material emission limit | |
|---|---|---|
| Furniture safety and dimensions | GB/T 3324 general technical requirements for wooden furniture | |
| Furniture test service | GB/T 10357 series, strength and durability test methods for furniture |
This product must meet the following technical requirements: 1. Formaldehyde emission: GB 18580interior decoration material emission limit; 2. Furniture safety and dimensions: GB/T 3324 general technical requirements for wooden furniture; 3. Furniture test service: GB/T 10357 series, strength and durability test methods for furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
