2-Person L-Shaped Partition Office Workstation with Mobile Pedestal (model WS-L2-1400-MP) is listed under L-Shaped Office Desk, with overall dimensions of 2800 × 2400 × 1100 mm and main material of Particle‑board (PB). Load capacity: 100 kg. Certifications: Modular,cubicle,partial,glass,partition,mobile,lockable,pedestal,under-desk,power,outlets. This page consolidates 6 groups of specifications and GB / EN / ANSI/BIFMA standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Finished Top Thickness | 50 mm | |
|---|---|---|
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Desktop static load capacity per seat | 100 kg | |
|---|---|---|
| Recommended user weight limit per seat | 136 kg | |
| Workstation unit net weight (single 2-seat set) | 165 kg | |
| Design service life | 8 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Work surface | 25mm thick melamine-faced particleboard with 2mm PVC edge banding | |
|---|---|---|
| Partition frame | 1.2mm thick extruded aluminum profile with powder-coated light gray finish | |
| Upper partition panel | 5mm thick frosted semi-transparent tempered glass with horizontal decorative strips | |
| Lower partition panel | 18mm thick MDF core with fabric-laminated teal gray surface | |
| Mobile pedestal body | 0.8mm thick cold-rolled steel with white epoxy powder coating | |
| Drawer handles | Beige ABS plastic pull handles with rounded profile |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Partition privacy function | 1100mm partial height divider blocks direct seated eye contact while allowing overhead light transmission | |
|---|---|---|
| Mobile pedestal storage | 3 lockable drawers (two stationery, one filing) with central lock, rolls fully under desk for space saving | |
| Under-desk power integration | Dual multi-socket power outlets pre-mounted on lower partition for laptop and device charging | |
| Modular expandability | Aluminum partition frames connect to additional cubicle modules for extended workstation clusters |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open plan office areas | Provides individual seated privacy for focused work while maintaining collaborative access | |
|---|---|---|
| Call center and back office departments | Modular design allows dense layout with integrated power to support high-density seating |
EU Market Access Requirements* EN Standards
| EN 527-2:2002+A1:2019 | Office worktables safety and strength requirements, applicable to desktop load and stability | |
|---|---|---|
| EN 1335-1:2020 | Office furniture workstation dimensions for ergonomic seated use |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Standard for office desks, applicable to static load, cycle and stability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Standard for mobile storage pedestals, applicable to drawer slide and lock performance |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable to desktop and panel components | |
|---|---|---|
| GB/T 3327-2017 | Technical requirements for office desks and workstations, applicable to structural load testing | |
| GB/T 14531-2017 | Office furniture partition panel performance requirements, applicable to cubicle divider systems |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable to desktop and panel components; 2. GB/T 3327-2017: Technical requirements for office desks and workstations, applicable to structural load testing; 3. GB/T 14531-2017: Office furniture partition panel performance requirements, applicable to cubicle divider systems; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
