4-Person Cross-Configured Office Cubicle Workstation with Integrated 3-Drawer Pedestals (model WS-CR4-2820-1200T) is listed under L-Shaped Office Desk, with overall dimensions of 2820 × 2820 × 1200 mm and main material of Particle‑board (PB). Load capacity: 91 kg. Certifications: Cross-shaped,modular,layout,fabric,privacy,partitions,integrated,drawer,storage,cable,management,system. This page consolidates 6 groups of specifications and GB / EN / ANSI/BIFMA standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall footprint | 2820 x 2820 x 1200 mm | |
|---|---|---|
| Desktop working height | 750 mm | |
| Single workstation desktop size | 1400 x 700 mm | |
| Under-desk knee clearance height | 680 mm | |
| Under-desk knee clearance depth | 600 mm | |
| Partition panel thickness | 60 mm | |
| Upper fabric partition height | 600 mm | |
| Lower solid modesty panel height | 600 mm | |
| Integrated 3-drawer pedestal size | 400 x 550 x 680 mm | |
| Desktop cable grommet diameter | 60 mm | |
| Drawer front panel height | 220 mm | |
| Adjustable foot height adjustment range | 15 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Single desktop static load capacity | 91 kg | |
|---|---|---|
| Drawer slide open/close cycle rating | 10000 cycles | |
| Total unit net weight reference | 250 kg | |
| Recommended maximum user weight per station | 136 kg | |
| Laminate desktop surface abrasion resistance | 2000 cycles | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Worksurface construction | 25mm thick E1 grade melamine-faced particleboard with 2mm PVC edge banding | |
|---|---|---|
| Upper partition panel construction | Fabric-upholstered fiberboard over steel frame with teal finish | |
| Lower modesty panel construction | 18mm thick matte grey melamine particleboard with black edge trim | |
| Support frame construction | 1.5mm thick powder-coated square steel tube with adjustable leveling glides | |
| Drawer hardware construction | 3-section full-extension cold-rolled steel ball-bearing slides with integrated key lock | |
| Pedestal cabinet construction | 16mm thick melamine particleboard with wood grain finish matching desktop |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Privacy partition design | Semi-enclosed cross dividers provide seated visual privacy for 4 adjacent users | |
|---|---|---|
| Storage configuration | One fixed 3-drawer pedestal per station stores stationery and A4/legal office files | |
| Cable management system | Undersurface cable trays and desktop grommets route power/data cables away from leg space | |
| Floor leveling adjustment | Bottom-mounted adjustable glides compensate for uneven office flooring without shimming |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open plan office spaces | Configures 4 individual work positions while maximizing floor space efficiency for medium teams | |
|---|---|---|
| Call center and administrative departments | Semi-private partitions reduce cross-talk distraction while retaining open office visibility |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable to structural performance verification | |
|---|---|---|
| EN 527-2:2016 | Office worktables dimensional safety and strength test methods, applicable for acceptance testing | |
| EN 13986:2004+A1:2015 | Wood-based panels for structural use in furniture, applicable to panel material compliance |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Office desk products performance and safety standard, recommended for commercial grade verification | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage pedestals and cabinets performance standard, applicable to integrated drawer units | |
| ANSI/BIFMA e3-2019 | Furniture sustainability standard, recommended for eco-friendly material selection verification |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable to worksurface and cabinet components | |
|---|---|---|
| GB/T 3327-2016 | Performance test methods for office desks and workstations, applicable for load and stability verification | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, required for indoor office air quality compliance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable to worksurface and cabinet components; 2. GB/T 3327-2016: Performance test methods for office desks and workstations, applicable for load and stability verification; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, required for indoor office air quality compliance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
