Name: 4-Person Linear L-Shaped Modular Office Cubicle Workstation Cluster with Mobile Lockable Pedestals
Brand: Fanshidun
SKU: BF8H5N

Time

Field

Original Value

Corrected Value

Note / Status

No correction records yet. Found an error? Click the flag at the end of a row to report it.

PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	3600 × 1500 × 1100 mm
Overall cluster dimensions	3600 x 1500 x 1100 mm
Work surface height	750 mm
Per-workstation primary work surface width	1400 mm
Per-workstation return surface depth	700 mm
Work surface thickness	25 mm
Privacy divider total height	1100 mm
Solid lower divider panel height	700 mm
Louvered upper divider panel height	400 mm
Under-desk knee clearance height	680 mm
Knee clearance depth per workstation	650 mm
Mobile pedestal dimensions	400 x 500 x 600 mm
Caster diameter	50 mm
Partition frame tube thickness	1.2 mm
Primary Component Thickness	40 mm according to load-bearing role
Hardware / Moving-part Clearance	5 mm operating clearance

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Total assembled cluster weight	280 kg
Static load capacity per work surface	150 kg
Work surface abrasion resistance	2000 cycles
Partition panel impact resistance	Grade 2
Caster rolling durability	20000 cycles
Recommended number of users	4
Product warranty	3 years
Reference Static Load	150 kg depending on category
Moving-part Durability Reference	Acceptance target 50000 cycles
Recommended Procurement Warranty	Structure 5 years; hardware 3 years

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Work surface substrate	E1 grade melamine-faced particle board
Partition frame	Powder-coated dark gray steel tube
Lower divider panel core	Medium density fiberboard with fabric wrap
Upper divider panel	Louvered steel slat panel with matching sage green finish
Rear modesty panel	Melamine-faced particle board matching light oak finish
Mobile pedestal cabinet body	Light oak melamine-faced particle board
Mobile pedestal drawer front	Sage green melamine-faced MDF
Casters	Black nylon swivel casters with brake lock
Connector hardware	Zinc-plated steel modular fasteners
Desktop edge banding	2mm thick PVC edge banding
Primary Connector Specification	Reference M6-M10 with at least 2 fixing points at major joints
Reference Finish / Color Count	Recommended 6finish options

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Modular assembly	Interlocking connector hardware supports reconfiguration of station counts
Cable management	Integrated cable port cutouts on each work surface for power and data routing
Mobile pedestal mobility	Four lockable swivel casters per pedestal allow repositioning under desk or adjacent use
Pedestal storage security	Integrated drawer lock secures all 3 drawers per pedestal for personal document storage
Privacy separation	1100mm high dividers block direct line of sight between seated adjacent workers
Ventilation design	Louvered upper divider panels allow air circulation between adjacent workstations
Knee well access	Open unobstructed under-desk clearance accommodates standard ergonomic office chairs
Surface resistance	Melamine desktop surface resists scratches, stains, and heat from standard office equipment
Reference Adjustment / Operating Range	100 mm or 120° where applicable

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Packaging Volume	0.8 m³/set
Reference Packaged Gross Weight	120 kg/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Open plan office spaces	Suitable for 4-person team work areas in corporate open offices, providing individual work zones
Call center environments	Appropriate for high-density customer service workstations with privacy and cable management
Startup and co-working spaces	Modular design supports flexible team expansion and layout reconfiguration for shared offices
Administrative staff areas	Designed for daily computer work, document processing, and personal storage for administrative personnel
Training department work areas	Durable construction supports frequent use in multi-person training and administrative support zones
Recommended matching furniture	Pair with mid-back ergonomic office chairs and desk lamps to complete individual workstations

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

EN 527-2:2002+A1:2019	Office worktables safety and strength requirements, applicable to work surface structural performance
EN 1335-2:2018	Office chair clearance compatibility, applicable to under-desk knee well dimension requirements
EN 1023-2:2000	Office storage furniture safety requirements, applicable to mobile pedestal components

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

ANSI/BIFMA X5.5-2021	Desk products standard, applicable to desktop load and durability testing benchmarks
ANSI/BIFMA X5.9-2019	Storage units standard, applicable to mobile pedestal structural performance benchmarks

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

GB/T 3324-2017	General technical requirements for wooden furniture, applicable to desktop and cabinet components
GB/T 3327-2016	Technical requirements for office desks, applicable to work surface height and load specifications
GB 18580-2017	Formaldehyde emission limits for wood-based panels, applicable to MDF/particle board components
GB/T 35607-2017	Requirements for office furniture panels, applicable to surface durability performance

Standardized tender description text

This product must meet the following technical requirements:
1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desktop and cabinet components;
2. GB/T 3327-2016: Technical requirements for office desks, applicable to work surface height and load specifications;
3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to MDF/particle board components;
4. GB/T 35607-2017: Requirements for office furniture panels, applicable to surface durability performance;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · CUB-4L-SG-OAK

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · CUB-4L-SG-OAK

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · CUB-4L-SG-OAKOpen Export Tool

Quick Actions

Post an RFQ

Product Description

The Fanshidun 4-Person Linear L-Shaped Modular Office Cubicle Workstation Cluster (model CUB-4L-SG-OAK) is a purpose-built public and commercial furniture solution designed to support structured, collaborative team workflows with dedicated individual work zones. Its linear L-shaped layout arranges four fully equipped workstations in a connected cluster, framed by privacy dividers that extend to match the total cluster height, with solid fabric-wrapped lower panels and louvered sage green upper slat panels creating a balanced visual profile. The light oak finish of work surfaces, modesty panels, and mobile pedestal bodies pairs with the muted green divider and drawer accents for a warm, professional aesthetic that integrates smoothly with modern office interiors, while the powder-coated dark gray steel partition frame delivers a crisp structural outline.
All components use durable, commercial-grade materials selected for consistent daily use. Work surfaces are constructed from E1 grade melamine-faced particle board, supported by zinc-plated steel modular fasteners that enable flexible reconfiguration. Lower divider cores use fabric-wrapped medium density fiberboard, while upper dividers are finished as louvered steel slats to support air flow between stations. Each workstation is paired with a mobile storage pedestal built from light oak melamine-faced particle board, with sage green melamine MDF drawer fronts, mounted on black nylon lockable swivel casters for easy repositioning.
Functional design details address core office workflow needs: integrated cable port cutouts on each work surface streamline power and data routing, the full height dividers block direct line of sight between seated adjacent users for focused work, and each pedestal includes a single integrated lock that secures all three drawers for personal document storage. The open, unobstructed under-desk clearance accommodates standard ergonomic office chairs, and the modular interlocking hardware supports adjustments to station counts as team needs evolve.
This workstation cluster is well suited for 4-person team zones in corporate open plan offices, high-density call center environments, flexible startup and co-working spaces, administrative staff work areas, and training department zones where regular multi-person use is expected. It pairs optimally with mid-back ergonomic office chairs and desk lamps to complete fully functional individual work setups.
Procurement teams should note the product ships in two cartons per set, with an assembly time of 40 minutes per unit, and is backed by a 3-year product warranty. The modular construction supports phased office expansion, and the durable material selection is engineered to withstand regular daily office use without premature wear.

4-Person Linear L-Shaped Modular Office Cubicle Workstation Cluster with Mobile Lockable Pedestals Specifications
