Automatic mm / inch conversion · Core engineering specifications
| Overall assembled dimensions | 3200 x 1600 x 1200 mm | |
|---|---|---|
| Desk working surface height | 750 mm | |
| Desktop thickness | 25 mm | |
| Partition height above desktop | 450 mm | |
| Knee well clearance height | 650 mm | |
| Knee well minimum width at corner | 800 mm | |
| Mobile pedestal dimensions | 400 x 440 x 600 mm | |
| Cable grommet diameter | 60 mm | |
| Adjustable glide adjustment range | 15 mm | |
| Single work surface arm length | 1600 mm | |
| Single work surface depth | 700 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Desktop uniform static load capacity | 100 kg | |
|---|---|---|
| Desktop surface abrasion resistance | 2000 cycles | |
| Desktop surface scratch hardness | 3H | |
| Frame and panel warranty period | 60 months | |
| Supported user weight per workstation | 136 kg | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop substrate | E1 grade melamine-faced particleboard | |
|---|---|---|
| Lower partition panels | Melamine-faced MDF with dark woodgrain laminate | |
| Upper privacy screens | Frosted translucent polycarbonate panel | |
| Partition frame trim | Powder-coated aluminum alloy profile, 1.2mm wall thickness | |
| Side support panels | Melamine-faced particleboard with white matte finish | |
| Mobile pedestal body | 0.8mm cold-rolled steel with white powder coating | |
| Pedestal drawer slides | 3-section full-extension ball-bearing steel slides | |
| Casters | 50mm diameter nylon swivel casters, 2 with brake locks | |
| Hardware fasteners | Zinc-plated steel connectors and screws | |
| Edge banding | 2mm thick PVC matching desktop finish | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Privacy partition system | Split divider with frosted upper screen and solid lower panel | |
|---|---|---|
| Cable management | 60mm round desktop grommet with internal cable channel | |
| Mobile storage pedestal | Rolling cabinet with 1 lockable drawer and 1 storage door | |
| Floor leveling system | 4 adjustable glide feet per desk segment | |
| Modular assembly | Knockdown connected frame design | |
| Pedestal mobility locks | 2 lockable casters on mobile pedestal | |
| Knee well access | Curved concave front desk edge at corner | |
| Rear modesty panel | Full-height solid panel below desk rear edge | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Open-plan office spaces | Suited for 2-person team clusters in corporate open office layouts | |
|---|---|---|
| Educational staff offices | Appropriate for teacher or administrative staff work areas in schools | |
| Startup and co-working spaces | Flexible modular design supports reconfiguration for growing teams | |
| Back-office administrative zones | Durable construction for high-traffic daily use in administrative departments | |
| Small business work areas | All-in-one workstation with integrated storage reduces additional furniture purchases |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable for structural performance | |
|---|---|---|
| EN 14073-2:2004 | Office storage furniture safety requirements, applicable for mobile pedestal performance | |
| EN 13722:2004 | Furniture caster performance requirements, applicable for pedestal wheel durability |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for performance and durability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard for mobile pedestal load and durability | |
| ANSI/BIFMA X5.11-2015 | Large occupant office furniture weight rating standard |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for panel structural performance | |
|---|---|---|
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable for desktop and panel substrate quality | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable for E1 grade compliance | |
| GB/T 10357.1-2013 | Furniture mechanical performance test for tables, applicable for desk load and stability |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for panel structural performance; 2. GB/T 4897.3-2003: Particleboard for furniture use, applicable for desktop and panel substrate quality; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable for E1 grade compliance; 4. GB/T 10357.1-2013: Furniture mechanical performance test for tables, applicable for desk load and stability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
