Single-Occupant L-Shaped Modular Cubicle Workstation Desk with Privacy Screens and Lockable Storage (model CUB-L1500-SCR-STG) is listed under L-Shaped Office Desk, with overall dimensions of 1500 × 1500 × 1200 mm and main material of Particle‑board (PB). Load capacity: 100 kg. Certifications: Modular,cubicle,structure,two-sided,privacy,screens,lockable,under-desk,storage,cable,grommet. This page consolidates 6 groups of specifications and GB / EN / ANSI/BIFMA standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall footprint (L-side x W-side x total partition height) | 1500 x 1500 x 1200 mm | |
|---|---|---|
| Desktop height from floor | 750 mm | |
| Desktop panel thickness | 25 mm | |
| Desktop usable depth (primary work area) | 600 mm | |
| Under-desk knee clearance height | 600 mm | |
| Under-desk knee clearance width (central opening) | 800 mm | |
| Partition panel total thickness | 40 mm | |
| Upper translucent slatted screen height | 350 mm | |
| Lower solid privacy panel height (partition section) | 650 mm | |
| Under-desk storage pedestal dimensions (W x D x H) | 400 x 550 x 725 mm | |
| Drawer internal usable height | 120 mm | |
| Lower cabinet internal usable height | 500 mm | |
| Cable grommet diameter | 60 mm | |
| Edge banding thickness (desktop and panels) | 2 mm | |
| Adjustable leveling foot height adjustment range | 15 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Desktop uniform static load capacity | 100 kg | |
|---|---|---|
| Drawer slide cycle durability | 50000 cycles | |
| Upper screen light transmittance | 50% | |
| Net product weight (assembled) | 95 kg | |
| Structural warranty period | 5 years | |
| Available finish color options | 4 | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Worksurface and solid panel core | E1 grade particleboard substrate | |
|---|---|---|
| Panel surface finish | Melamine laminate overlay | |
| Partition frame material | Anodized aluminum alloy extrusion | |
| Upper privacy screen section | Translucent ribbed polycarbonate slats | |
| Drawer slide hardware | Cold-rolled steel 3-section ball-bearing slides | |
| Pedestal lock mechanism | Zinc alloy keyed cam lock |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable management system | Round desktop grommet with under-desk cable channel | |
|---|---|---|
| Storage configuration | 1 lockable upper drawer + 1 lockable lower cabinet door | |
| Leveling adjustment | Threaded plastic-capped adjustable feet at all base corners | |
| Modular connection | Aluminum frame bracket connectors |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open-plan office single staff workstations | Provides dedicated private work space with partial sightline and noise screening | |
|---|---|---|
| Call center and back-office cubicle banks | Modular connectors allow linear or clustered layout expansion |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety, strength and durability requirements for commercial workstations | |
|---|---|---|
| EN 13986:2004+A1:2015 | Wood-based panels for structural use, performance requirements for furniture applications |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard, safety and durability performance for office worksurfaces | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard, load and cycle performance for under-desk pedestals |
Standards applicable to China-market projects
| GB 18580-2017 | Formaldehyde emission limit for wood-based panels, ≤0.124 mg/m³ for indoor office use | |
|---|---|---|
| GB/T 3324-2017 | General technical requirements for wooden office furniture, structural safety and dimensional tolerance standards |
This product must meet the following technical requirements: 1. GB 18580-2017: Formaldehyde emission limit for wood-based panels, ≤0.124 mg/m³ for indoor office use; 2. GB/T 3324-2017: General technical requirements for wooden office furniture, structural safety and dimensional tolerance standards; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
