Single-Person L-Shaped Office Cubicle Workstation with Mobile Pedestal (model CUB-L1600-MP3-PWR) is listed under L-Shaped Office Desk, with overall dimensions of 1600 × 1600 × 1200 mm and main material of Particle‑board (PB). Load capacity: 100 kg. Certifications: Modular,structure,L-shaped,corner,layout,half-glass,partition,mobile,under-desk,pedestal,integrated,power,outlets. This page consolidates 6 groups of specifications and GB / EN / ANSI/BIFMA standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall footprint | 1600 x 1600 x 1200 mm | |
|---|---|---|
| Work surface height | 750 mm | |
| Work surface thickness | 25 mm | |
| Partition panel total height | 1200 mm | |
| Partition panel thickness | 60 mm | |
| Upper glazed partition section height | 480 mm | |
| Lower solid modesty panel height | 720 mm | |
| Seated knee clearance height | 650 mm | |
| Knee opening width | 900 mm | |
| Under-desk clearance depth | 600 mm | |
| Mobile pedestal dimensions | 400 x 500 x 600 mm | |
| Mobile pedestal drawer internal height | 150 mm for top two drawers, 250 mm for bottom file drawer | |
| Caster wheel diameter | 50 mm | |
| Cable grommet diameter | 60 mm | |
| Leveling foot adjustment range | 15 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Work surface static load capacity | 100 kg | |
|---|---|---|
| Product net weight | 95 kg | |
| Recommended maximum user weight | 120 kg | |
| Laminate surface scratch resistance | 2000 cycles | |
| Warranty period | 5 years | |
| Available finish color options | 60 | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Work surface | 25mm thick MFC board with melamine laminate finish, 2mm PVC edge banding | |
|---|---|---|
| Partition frame | 1.2mm thick extruded aluminum alloy profile with powder coated silver finish | |
| Upper partition panel | 5mm thick tempered frosted glass with horizontal striped pattern | |
| Lower modesty panel | 18mm thick melamine-faced particleboard with light gray finish | |
| Mobile pedestal | 18mm thick melamine-faced MDF cabinet, steel ball-bearing drawer slides, lock core with 2 keys | |
| Desk support frame | 1.5mm thick rectangular steel tubing with powder coated finish, nylon adjustable leveling feet |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Integrated power module | 2 AC power outlets mounted on rear modesty panel for desktop device power access | |
|---|---|---|
| Cable management | Rear under-desk cable channel and desktop grommets to route and conceal power/data cords | |
| Mobile storage pedestal | 3 lockable drawers on swivel casters, rolls fully under desk for personal file and supply storage | |
| Modular partition connection | Interlocking aluminum frame connectors allow reconfiguration or connection to adjacent workstations |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open plan office staff workstations | Provides individual visual and acoustic privacy for focused task work in open offices | |
|---|---|---|
| Small business team work areas | Modular design allows expansion into multi-station clusters as team size grows |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables and desks, safety and strength requirements for work surfaces | |
|---|---|---|
| EN 1335-1:2020 | Office furniture, office work chair dimensional coordination for desk clearance |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for strength, durability and structural stability | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard for mobile pedestal performance and drawer durability |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desktop and pedestal components | |
|---|---|---|
| GB/T 3325-2017 | Test methods for metal furniture, applicable to steel frame and hardware components | |
| GB 28007-2011 | Safety requirements for children's and adult office furniture, applicable to structural stability |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desktop and pedestal components; 2. GB/T 3325-2017: Test methods for metal furniture, applicable to steel frame and hardware components; 3. GB 28007-2011: Safety requirements for children's and adult office furniture, applicable to structural stability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
