Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall cluster footprint | 2880 x 2120 x 1200 mm | |
|---|---|---|
| Individual workstation nominal bay | 1400 x 1200 mm | |
| Work surface height | 750 mm | |
| Work surface thickness | 25 mm | |
| Curved knee opening width | 800 mm | |
| Under-desk knee clearance height | 673 mm | |
| Under-desk knee depth | 600 mm | |
| Privacy panel height above floor | 1200 mm | |
| Privacy panel thickness | 41 mm | |
| Drawer pedestal footprint | 400 x 498 x 654 mm | |
| Cable grommet diameter | 60 mm | |
| Modesty panel height | 450 mm | |
| Square support leg section | 45 x 45 mm | |
| Leveling foot diameter | 30 mm | |
| Storage drawer front height | 160 mm top drawer, 420 mm lower drawer | |
| Primary Component Thickness | 40 mm according to load-bearing role |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Number of occupants | 4 staff seats | |
|---|---|---|
| Per-workstation distributed load | 113 kg | |
| Total cluster indicative weight | 512 kg | |
| Pedestal drawer static load | 25 kg per drawer | |
| Caster capacity per pedestal | 60 kg total | |
| Privacy panel tacking capacity | 2 kg per panel face | |
| Modesty panel lateral load | 20 kg | |
| Floor leveling compensation | 10 mm per foot | |
| Warranty duration | 5 years | |
| Reference Static Load | 150 kg depending on category |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Work surface | 25 mm wood-grain thermally fused laminate on particleboard core | |
|---|---|---|
| Edge treatment | 2 mm matching-color PVC edge banding | |
| Privacy panel fabric | Woven gray polyester fabric over padded core | |
| Privacy panel core | Foam-padded MDF composite core, 41 mm thick | |
| Screen frame | Extruded aluminum perimeter frame with light silver anodized or powder finish | |
| Desk support frame | Square powder-coated steel legs and rectangular under-top rails | |
| Modesty panels | Dark gray rigid composite panel with horizontal lower rail | |
| Pedestal cabinet body | Light gray melamine panel with wood-grain drawer fronts | |
| Drawer hardware | Ball-bearing side-mount drawer slides with integrated lock cylinder | |
| Leveling feet | Injection-molded black nylon feet with steel threaded stems | |
| Cable grommet | 60 mm round plastic grommet with brushed metallic cap | |
| Fasteners and connectors | Zinc-plated or blackened steel cam, bolt and bracket hardware |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Four-way privacy layout | Cross-mounted screens divide the cluster into four outward-facing seated work bays | |
|---|---|---|
| Curved ergonomic front edge | Each work surface has a concave front edge giving an 800 mm knee opening | |
| Integrated personal storage | Each position uses a compact two-drawer pedestal with lockable top drawer | |
| Drawer operation | Two drawers open on side-mount slides; lower drawer accommodates suspended files up to 420 mm front height | |
| Cable routing | A 60 mm desktop grommet passes monitor and power cables into the under-desk zone | |
| Separated power/data path planning | Under-desk trough layout supports separate strong-current and weak-current channels | |
| Screen attachment | Aluminum-framed panels connect at a central X-junction and desk-side vertical posts | |
| Floor leveling | Threaded nylon feet adjust up to 10 mm to compensate for uneven floors | |
| Modular expansion | Cluster brackets and repeated screen posts allow additional bays to join the system | |
| Knock-down installation | Desk tops, panels, pedestals and frames ship separately and bolt together on site | |
| Mobile pedestal movement | Pedestals use five swivel casters, two with brakes, when specified as mobile configuration | |
| Seated privacy control | 1200 mm screens block direct sight lines while retaining open-office visibility above seated users |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Largest carton dimensions | 1500 x 1100 x 120 mm | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open-plan office | Suitable for four staff in a compact 2880 x 2120 mm cluster with separated seated bays. | |
|---|---|---|
| Administration and finance teams | Lockable drawer pedestals support personal documents and daily office supplies at each seat. | |
| Call centers and shared service centers | Low screens reduce visual distraction while retaining supervisor visibility across the cluster. | |
| Project teams | Four nearby positions support short collaboration while preserving individual monitor and writing space. | |
| Small-to-medium enterprise fit-out | Standard 750 mm work height and 25 mm tops fit mainstream office seating and equipment. | |
| Flexible office expansion | Cross-cluster connectors allow additional four-person modules to form larger departmental layouts. | |
| Procurement configuration | Use as a complete workstation package requiring chairs, monitors and power outlets to be specified separately. |
EU Market Access Requirements* EN Standards
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.5 Desk and Table Products |
|---|
Standards applicable to China-market projects
| GB/T 3324-2024 | General technical requirements for wooden furniture, applicable to laminate desks and cabinet bodies during procurement inspection. | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limit for wood-based panels, applicable to particleboard and MDF components. | |
| GB/T 15102-2017 | Requirements for impregnated paper laminated wood-based flooring and panel finishes, useful for laminate surface verification. | |
| GB/T 35607-2024 | Furniture material identification guidance, applicable when validating board, metal and fabric declarations. | |
| GB 18584-2024 | Indoor wooden furniture harmful-substance limits, applicable to office furniture used indoors. | |
| GB/T 35601-2024 | Green product furniture evaluation, applicable only if supplier provides a matching test report. |
This product must meet the following technical requirements: 1. GB/T 3324-2024: General technical requirements for wooden furniture, applicable to laminate desks and cabinet bodies during procurement inspection.; 2. GB 18580-2017: Formaldehyde emission limit for wood-based panels, applicable to particleboard and MDF components.; 3. GB/T 15102-2017: Requirements for impregnated paper laminated wood-based flooring and panel finishes, useful for laminate surface verification.; 4. GB/T 35607-2024: Furniture material identification guidance, applicable when validating board, metal and fabric declarations.; 5. GB 18584-2024: Indoor wooden furniture harmful-substance limits, applicable to office furniture used indoors.; 6. GB/T 35601-2024: Green product furniture evaluation, applicable only if supplier provides a matching test report.; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
