| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall footprint | 2800 x 2800 x 1200 mm | |
|---|---|---|
| Desktop working height | 750 mm | |
| Per-seat L-shaped work surface | 1400 x 1200 mm | |
| Desktop thickness | 25 mm | |
| Knee clearance height under desk | 650 mm | |
| Privacy partition total height | 1200 mm | |
| Partition panel thickness | 32 mm | |
| Under-desk storage pedestal dimensions | 400 x 600 x 600 mm | |
| Desktop cable grommet diameter | 60 mm | |
| Modesty panel height under desk | 450 mm | |
| Concave front edge radius per seat | 300 mm | |
| Pedestal drawer internal clearance | 120 mm | |
| Pedestal cabinet internal clearance | 450 mm | |
| Frosted louver upper section height | 250 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Per-work-surface static load capacity | 91 kg | |
|---|---|---|
| Total set net weight | 260 kg | |
| Recommended user capacity | 4 people | |
| Surface abrasion resistance | 2000 cycles | |
| Formaldehyde emission grade | E1 | |
| Structural warranty period | 5 years | |
| Surface finish warranty period | 2 years | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desktop panel | 25mm melamine-faced particleboard, PVC edge banding | |
|---|---|---|
| Partition frame | 1.2mm thick extruded aluminum alloy, silver anodized finish | |
| Lower partition panel | Fabric-covered medium density fiberboard, green finish | |
| Upper partition panel | Frosted louvered acrylic panel with horizontal slits | |
| Storage pedestals | 18mm melamine-faced particleboard, matching light wood and white finish | |
| Desk support frame | 1.5mm thick square steel tube, powder coated white |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Integrated cable management | 60mm desktop grommets and under-desk cable trays route power and data cords | |
|---|---|---|
| Lockable storage per seat | One keyed lock secures top stationery drawer and lower cabinet door per position | |
| Modular connection system | Cross corner connectors allow knock-down assembly and layout reconfiguration | |
| Partial privacy screening | 1200mm high dividers block direct line of sight between adjacent seated users |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Open plan office staff areas | Provides semi-private dedicated workstations for teams of 4 employees | |
|---|---|---|
| Call center and administrative departments | Dividers reduce distraction while maintaining supervisor visibility |
EU Market Access Requirements* EN Standards
| EN 527-2:2002+A1:2019 | Safety and strength requirements for office work tables, applicable to desk structure | |
|---|---|---|
| EN 717-1:2004 | Formaldehyde emission testing for wood-based panels, applicable to panel materials |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Performance standard for desk products, applicable to load and stability validation | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Performance standard for office storage units, applicable to pedestal cabinets |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable to desktop and cabinet components | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to engineered wood components | |
| GB/T 3327-2016 | Performance test methods for office desks, applicable to desktop load and stability checks |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable to desktop and cabinet components; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to engineered wood components; 3. GB/T 3327-2016: Performance test methods for office desks, applicable to desktop load and stability checks; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
